Step 2: End Wall Prep
Part 2
It is important to assemble the frame on a at, smooth surface.
D:Turntheassemblyoverthenattachallboardswith6(H9)HexBolts(withlockwasherandatwasher)
connectingtothepreviouslyinstalledt-nuts.(g.2.3and2.4)
6 x Hex Bolt
(lock washer & at washer)
H9
Hardware
Fig. 2.4
Fig. 2.3
2768
2769
H9
H9
x2perboard
2769
2770
2771
FW1
LW1
