SELWOOD Mint - Page 10

 10 www.selwood.com
Step 2: End Wall Prep
Part 1
It is important to assemble the frame on a at, smooth surface.
A:Place(2768)PanelFloorand2(2769)PanelBTFramesonahard,atsurfacewiththelongsideup.Tapin
2(TN1)T-nutsperboard.(g.2.1)
B:Place(2771)EndPostand(2770)EndPostLeftsidebysidewiththegroovesfacingupandin.(2770)End
PostLeftontherighthandside.Place(2769)PanelBTFramesinthetopandbottomgrooves(2768)Panel
Floorinthemiddlegrooves.(g.2.2).
C:Makesureassemblyissquarethenattachwith4(S30)WoodScrewsperboard.(g.2.2)
12 x Wood Screw
6 x T-nut
1 x Panel Floor
2 x Panel BT Frame
1 x End Post
1 x End Post Left
S30
2768
Wood Parts
Hardware
2771
2770
2769
Fig. 2.2
Fig. 2.1
Bottom
Top
2768
2770
2771
2769
S30
x4
Flush
Flush
2769
Flush
S30
x4
S30
x4
2768
2769
2769
TN1
TN1
TN1
TN1
