It is important to assemble the frame on a at, smooth surface.
D:Turntheassemblyover,place(2774)Uprightinthemiddlegrovesof(2775)PanelCrossSupportand(2772)
PanelFloorSupportthenattachallboardswith8(H9)HexBolts(withlockwasherandatwasher)connectingto
thepreviouslyinstalledt-nuts.(g.1.3and1.4)
E:RepeatstepsA-Dforasecondassembly.
16 x Hex Bolt
(lock washer & at washer)
2 x Upright
H9
Wood Parts Hardware
2774
Fig. 1.4
Fig. 1.3
2772
Flush
2775
2774
H9
H9
H9
H9
x3
x3
x2
Step 1: Front and Back Wall Prep
Part 2
2770
2771
FW1
LW1
