SELWOOD Mint - Page 20

 20 www.selwood.com
2 x Side Joist MOD
B:OntheinsideofboththeFrontandBackWallslooselyattach1(2777)SideJoistMODtoeach(2772)Panel
FloorSupportwith2(H11)HexBolts(withlockwasher,atwasherandt-nut)asshowning.5.5.Makesure
both(2777)SideJoistMODsarelevelwith(2608)FloorJoist.
Step 5: Floor Assembly
Part 2
2777
Wood Parts
4 x Hex Bolt
(lock washer, at washer, t-nut)
Hardware
H11
Fig. 5.5
FW1
LW1
H11
H11
2772
2772
2777
2777
2608
TN1
TN1
FW1
LW1
Back Wall
Front Wall
