A:Frominsideoftheassemblycentre(2608)FloorJoistoverthepilotholesinboth(2768)PanelFloorsinthe
SwingandEndWalls,measure5/8”(15.9mm)downfromthetopofboardsthenattach(2608)FloorJoisttoeach
boardusingtheleftandcentreholeswith2(S4)WoodScrewsperboard.(g.5.1,5.2,5.3and5.4)
Step 5: Floor Assembly
Part 1
1 x Floor Joist
2608
Fig. 5.2
Wood Parts
Fig. 5.1
2608
Fig. 5.3
Hardware
4 x Wood Screw
S4
2768
5/8”(15.9mm)
2768
Swing Wall
End Wall
2608
2768
End Wall
Swing Wall
S4
S4
Fig. 5.4
Notice holes used
