CM2125 SPECIFICATIONS:
Outputs:
Bandwidth: 125 MHz
Horizontal pixel resolution: 80 - 2048 pixels
Vertical pixel resolution: 80 - 2048 pixels
Horizontal scan frequency: 10 - 250 KHz
Vertical scan frequency: 10 - 250 Hz
Output amplitude: TTL, analog, or ECL
Mode selection: Interlaced or non-interlaced
Gun selection: RGB
Sync adder: RGB
Polarity selection: Video, H-Sync, V-Sync
Sync Timing:
The CM2125 recognizes common computer monitor formats and automatically adjusts
for the correct sync, back porch, and front porch timing.
Sync timing parameters can be changed through the front panel.
Memory:
70 computer monitor setup storage locations (42 preprogrammed).
Video Patterns:
Raster Dots Circle/Crosshatch
Color Bars Multiburst Staircase
Text Window Windows
Drive Signals:
Signal at zero: Less than 3% of full range
Output at full level:
3 V range: 3 VPP, ± 0.5 V into 100 ohms
30 V range: 30 VPP, ± 5 V into 100 ohms
300 V range: 300 VPP, ± 50 V into 10,000 ohms
Clipping: None up to 250 VPP typical
Protection from externally applied voltage: ± 500 V (DC + peak AC)
Floating ground (-) Isolated by ± 500 V (DC + peak AC)
External VPP:
3 ranges (auto-ranged): 0.0 - 19.9VPP, 20 - 199 VPP, 200 - 1999 VPP
Accuracy: (All) ± 1%, ± 2 counts
Frequency response: 0 - 200 V, 30 Hz to 5 MHz, t/-l dB from the average value across
the band
Input impedance: 15 Megohm
External VDC:
3 ranges (auto-ranged): 00.00 - 19.99 V DC, 20.0 - 199.9 V DC, 200 - 1999 V DC
Accuracy: (All) ± .2%, ± 2 counts
Input Impedance: (Without probe) 15 Megohm
Meter Protection:
2000 V DC (DC + peak AC), across the inputs. Maximum voltage between (-) lead and
ground: 1500 (DC + peak AC)
Ringing Test:
Dynamic test of coil Q determined by counting the number of ringing cycles before
reaching a preset damping point. The preset damping point IS set at 25% of the excitation
pulse The number of cycles
IS displayed on the digital display and continually updated.
General:
Digital meters: 3 ½ digit, LCD readout Digital display: LCD readout
Guaranteed operating temperature: 15-35 degrees C
Size: 6” x 12” x 14.3” (HWD)
Power: 105-125 VAC, 60 Hz, 140 w max.
Supplied Accessories:
Test lead, BNC to EZ hook probes
Test lead, 72” banana-probe, red
Test lead, 72” banana-alligator, black
Optional Accessories:
Extension Cable
BNC Cable
Universal Connector (Adapts to match any computer type)
Connector #1 (CGA, MDA, Hercules)
Connector #2 (EGA)
Connector #3 (PGC)
Connector #4A (VGA, PS/2, SVGA, XGA)
Connector #6 (BNC Input)
Connector #7 (13 W3)
Connector #8 & 8F* (Apple/MAC) * Monitor with male input connection.
ECL Adapter (ECL Monitors)
IB72 IEEE-488 Interface Accessory
IB78 RS232 Interface Accessory
PC263 Protective Cover
HP200 50 kV High Voltage Probe
TP212 10 kV Transient Protector Probe
Sencore’s Exclusive After-The-Sale Support
All Sencore Instruments Are Backed By Our Exclusive 30 Day Money Back Guarantee
‘If you are not completely satisfied with any Sencore instrument, you may return it during the first 30 days, and we’ll give you a full refund,
including freight, no questions asked.”
Toll Free Access To The Entire Factory
Sencore does not stop providing assistance after you purchase one of our instruments. We provide free technical assistance on any
instrument use questions, future purchase assistance, industry trend information, instrument service, or any question you may have on test
instruments. Just call Sencore at our toll free
1-800-SENCORE
number, Your Area Sales Engineer, an Application Engineer, or a Service
Technician will be happy to assist you.
Made Right Guarantee
In addition to the 1 year warranty on parts and labor (less than 2%
CM2125
Computer Analyzer
are returned for warranty service), Sencore offers you a 100% Lifetime
Made Right Guarantee. We guarantee your instrument was
Ordering the
CM2125 Computer Monitor Analyzer
engineered right the first time. If there’s a problem, we’ll make it right,
is as simple as picking up your phone. Call
for the lifetime of the instrument.
1-800-SENCORE
(736-2673) and talk directly with
your Area Sales Engineer about the many
Extended Service Agreement Programs (ESA)
Programs available to
help with your instrument
Sencore announces our new Extended Service Agreement Programs
for your CM2125. These programs can be an extension of your
warranty coverage or simply a method for you to have annual calibrations at a reduced rate. For further information regarding these
programs, please contact your Area Sales Engineer or the Service Department.
Call 1
-800-SENCORE
Form
#5659A
(736-2673)
