Seneca Z109PT2-1 User Manual

ENGLISH 3/8
MI004284-E
Errors referred to maximum
measuring range:
Calibration
Error
Thermal
Coefficient
Linearity
Error
EMI
Thermoresistance RTD Input:
PT100, PT500, PT1000, NI100 (1)
0.1%
0.01%/°K
0.02% (se t > 0°C)
0.05% (se t < 0°C)
<1% (2)
Voltage output (3)
0.3%
0.01%/°K
0.01%
(1) All the values have to be calculated on the resistive value.
(2) Influence of cable resistance 0.005%/max 20 .
(3) Values to be added to the errors of the selected input.
INSULATIONS 1500V
STANDARDS
The module complies with the following standards:
EN61000-6-4 (electromagnetic emission,
in industrial environment)
EN61000-6-2 (electromagnetic immunity,
in industrial environment)
EN61010-1 (safety)
Notes:
- Use with copper conductor.
- Use in Pollution Degree 2 Environment
- Power Supply must be Class 2
- When supplied by an Isolated Limited Voltage and/or
Limited Current power supply, a fuse rated max 2.5 A
shall be installed in the field.
1500 V insulating voltage is among:
- power supply
- analog input
- analog output
3.3 CONNECTIONS
USB Interface
Micro USB connector (frontal panel)
3.4 POWER SUPPLY
Supply Voltage
10-40 V, 19-28 V 50-60 Hz, through screw terminals: 2 – 3
Power supply unit
Classe 2
Power consumption
1.6 W @ 24 V with output 20 mA; Max: 2.5 W
3.5 MODULE CASE
Case
PA6, black color
Dimensions
Width L=100mm; Height H=112mm; Depth W=17,5mm
Board terminals
2
Removable 3 way screw terminals: pitch 5.08mm, section 2.5mm
Protection class
IP20
3.6 ENVIRONMENTAL CONDITIONS
Operating
Temperature
-10°C – +60°C (UL: -10°C – +60°C)
2
3
6
USB
POWERSUPPLY
1
ANALOG
OUT
10
11
12
9
8
7
1500 V
THERMO-
RESISTANCE
INPUT

Seneca Z109PT2-1 Specifications

General

Brand	Seneca
Model	Z109PT2-1
Category	Control Unit
Language	English
