Seneca Z109PT2-1 User Manual

ENGLISH 8/8
MI004284-E
SETTINGS THROUGH
INTERNAL JUMPERS
ACTIVE / PASSIVE OUTPUT
Active Output Passive Output
J9
SW1
SW2
SW3
FRONTAL PANEL
MODULE DIMENSIONS
Disposal of Electrical & Electronic Equipment (Applicable throughout the European Union and
other European countries with separate collections programs). This symbol, found on your
product or on its packaging, indicates that this product should not be treated as household waste
when you wish to dispose of it. Instead, it should be handed over to an applicable collection point
for the recycling of electrical & electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences to the environment and human
health, which could otherwise be caused by inappropriate disposal of this product. The recycling of
materials will help to conserve natural resources. For more detailed information about the
recycling of the product, please contact your local city office, waste disposal service of the retail
store where you purchased this product.
9. DECOMMISSIONING AND DISPOSAL
8. MODULE LAYOUT
ORDER CODE
SPECIFICATIONS
CU-A-MICROB
USB-microUSB 1 mt communication cable.
CU-A-MICRO-OTG
Adapter cable for smartphone.
7. PURCHASE ORDER CODE
LED
LED STATE
LED MEANING
PWR
Green
ON
Power supply presence
Blinking (freq: 1 flash./sec)
Out of Scale, Burn Out or Internal failure
Blinking (freq  2 flash./sec)
DIP-switches setting error
6.6 LED INDICATIONS ON THE FRONTAL PANEL
6.5 JUMPERS POSITION
J9
J9
11
12
10
1
1
1.0 mm
17.5 mm
100 mm
Z109PT2-1
Z109PT2-1
8
9
7
USB
Z109PT2-1
PWR/
FAIL
