SENLAN SB40 PERIPHERAL DEVICES
- 70 -
Table 8-2 Braking resistor specifications
Capacity
(kW)
Resistance
(Ω)
Capacity
(kW)
Resistance
(Ω)
11
60Ω/2.5 kW
75
2×20Ω/20 kW
15
50Ω/4 kW
90
2×20Ω/20 kW
18.5
40Ω/4 kW
110
2×13.6Ω/27 kW
22
30Ω/5 kW
132
2×13.6Ω/27 kW
30
24Ω/8 kW
160
2×20Ω/33 kW
37
20Ω/8 kW
200
5×20Ω/40 kW
45
16Ω/12 kW
220
4×13.6Ω/45 kW
55
13.6Ω/12 kW
280
5×13.6Ω/64 kW
Table 8-3 Braking unit specifications
Type
resistance(Ω)
capacity(kW)
SZ10G11/22
≥20 ≥1
SZ10G30/45
≥10 ≥3
SZ10G55/90
≥5.1 ≥7
SZ10G110/132
≥3.3 ≥10
SZ10G110/200
≥2.2 ≥12.5
