60 | All-Day Clear All-Day Clear | 61
Technical specifications
Measurements Value Reference
Standard
Maximum output limit value (OSPL90) 110 dB SPL ANSI S3.22
2014
Maximum output (OSPL90) curve see Figure 1
Full On Gain Value @50 dBSPL input 34 dB ANSI S3.22
2014
Frequency Response Curve see Figure 2
Output Distortion
100dB SPL Out 1.0% ANSI/CTA
2051 2017
70dB SPL Out 4.0% ANSI/CTA
2051 2017
Input Distortion @ 100dB SPL In 1.0% ANSI/CTA
2051 2017
Self Generated Noise value 25 dB SPL ANSI/CTA
2051 2017
Latency Value 6.5 ms
(milli-
seconds)
ANSI/CTA
2051 2017
Upper and Lower Cut-off Frequencies
for Bandwidth
100 Hz to
5000 Hz
ANSI/CTA
2051 2017
provide “normal use”; a sum of 6 or greater would
indicate “excellent performance”. The equipment
performance measurements, categories and system
classifications are based upon the best information
available but cannot guarantee that all users will be
satisfied. The immunity of this hearing aid is at least
M2/T2.
the performance of individual hearing aids may
vary with individual cell phones. Therefore,
please try the hearing aid with your cell phone or,
if you are purchasing a new phone, be sure to try
it with your hearing aid prior to purchase.
Important information in case of battery ingestion
If a battery is swallowed, consult your physician
immediately.
