A
Connection to a fixed line
phone without headset
socket
Putting the headset system into operation
12
왘 Disconnect the handset cable from the telephone.
왘 Connect the handset cable to the Handset socket
.
왘 Use the telephone cable  to connect the Phone socket  to the
handse
t socket on the telephone.



왘 Set the DIP switch  #1 and #2 to the upper position.
B
Connection to a fixed line
phone with headset socket
왘 Use the telephone cable  to connect the Phone socket  to the
headset socket on the telephone.


왘 Set the DIP switch  # 1 and # 2 to the upper position.
