Sennheiser E 901 - Specifications; Connector Assignment

5
Specifications
Transducer principle pre-polarized condenser microphone
Frequency response 20 ... 20,000 Hz
Pick-up pattern half-cardioid
Sensitivity
(free field, no load at 1 kHz) 0.5 mV/Pa
Nominal impedance (at 1 kHz) < 100 Ω
Min. terminating impedance 1 kΩ
Connector XLR-3
Dimensions 126.5 x 105 x 26.5 mm
Weight 550 g
The polar diagram and the frequency response curve C can be found on
the cover pages.
Connector assignment
12
3
1
2
3
+ +
1
2
3
XLR 6.3 mm
+
+
12
3
XLR
+
XLR
1
2
3
6.3 mm
+
+
balanced
XLR
XLR
+
