Model e 912 S BK e 912 S NX e 912 S WH
Cat. No. 500875 (black) 502193 (Nextel gray) 500876 (creme white)
EAN No. 40 44155 00820 3 40 44155 02456 2 40 44155 01467 9
UPC No. 6 15104 12225 3 6 15104 13661 8 6 15104 12234 5
Transducer principle
pre-polarized
condenser microphone
pre-polarized
condenser microphone
pre-polarized
condenser microphone
Frequency response 20 – 20,000 Hz 20 – 20,000 Hz 20 – 20,000 Hz
Pick-up pattern half-cardioid half-cardioid half-cardioid
Sensitivity (free field, no load) (1 kHz) 6 (10) mV/Pa 6 (10) mV/Pa 6 (10) mV/Pa
Nominal impedance 0.1 kO 0.1 kO 0.1 kO
Min. terminating impedance > 1 kO > 1 kO > 1 kO
Phantom powering
48 V/1.4 mA 48 V/1.4 mA 48 V/1.4 mA
Max. sound pressure level at 1 kHz 134 dB SPL 134 dB SPL 134 dB SPL
Connector XLR-3 XLR-3 XLR-3
Dimensions (L x W x H) 5 in. x 4.1 in. x 1.04 in. 5 in. x 4.1 in. x 1.04 in. 5 in. x 4.1 in. x 1.04 in.
Weight 1.2 lbs 1.2 lbs 1.2 lbs
02/07 Printed in USA Sennheiser is registered trademark of Sennheiser electronic GmbH & Co. KG.
Polar diagram Frequency response curve
0˚
5
10
15
20
25
dB
30˚
60˚
90˚
30˚
60˚
90˚
120˚
150˚
180˚
150˚
120˚
2000 Hz
4000 Hz
8000 Hz
16000 Hz
125 Hz
250 Hz
500 Hz
1000 Hz
0
Hz
dBV
-20
-30
-40
-50
-60
-70
50 100 200 500 1k 2k 5k 10k 20k
Black: low and high boost (preset)
Red: low cut (+ preset)
Green: lin (e 912)
Blue: low boost
Specifications
Hz
dBV
-20
-30
-40
-50
-60
-70
50 100 200 500 1k 2k 5k 10k 20k
Black: low and high boost (preset)
Red: low cut (+ preset)
Green: lin (e 912)
Blue: low boost
Sennheiser Electronic Corporation, One Enterprise Drive, Old Lyme, CT 06371 • Tel:(860) 434-9190 • Fax: (860) 434-1759 • www.sennheiserusa.com
