Sennheiser e 935 - Sennheiser e 935 Specifications; Connector Wiring Assignments

4
Specifications
Transducer principle dynamic
Frequency response 40 … 18,000 Hz
Pick-up pattern cardioid
Sensitivity (free field, no load at 1 kHz) 2.8 mV/Pa
Nominal impedance (at 1 kHz) approx. 350 Ω
Min. terminating impedance 1 kΩ
Connector XLR-3
Temperature range 0 °C to +40 °C
Dimensions Ø 47 x L 151 mm
Weight 355 g
The polar diagram and the frequency response curve D can be found on
the cover pages.
Connector assignment
12
3
1
2
3
+ +
1
2
3
XL
R6
.3 mm
+
+
12
3
XLR
+
XLR
1
2
3
6.3 mm
+
+
balanced
XLR
XLR
+
