17
Replacing the connecting cable
Replace the connecting cable if it is damaged. To do so,
please proceed as follows:
씰 Remove the ear cushion. Grasp behind the ear cushion
and pull it up and away from the earcup.
씰 Loosen the screw and remove it.
씰 Remove the cover from the earcup .
씰 Pull the connector out of the socket.
씰 Remove the antikink protection of the connecting cable
from the holding device .
씰 Insert the antikink protection of the new connecting
cable into the holding device.
씰 Plug the connector of the new connecting cable into
the socket as shown in the diagram on the left.
씰 Put the cover back onto the earcup .
씰 Replace the screw and tighten it.
씰 Slide the ear cushion onto the earcup.
Converting the headphones into a headset
If you wish to convert your headphones into a headset,
please contact your Sennheiser service partner who will
equip the headphones with a microphone.
