Sennheiser HD 280 - Specifications and Performance; Product Specifications; Frequency Response Curve

18
dB
(1 Pa/V)
Hz
Specifications
HD 280 pro
HD 280 silver HD 280-13
Classification
(as per IEC 268-7) 268-7-IEC-DCSC-64R0-2  268-7-IEC-DCSC-03R2-2
Transducer principle dynamic  dynamic
Impedance 64 Ω (as per IEC 268-7)  300 Ω (as per IEC 268-7)
Long-term max. input power 0.5 W (as per IEC 268-7)  0.5 W (as per IEC 268-7)
Ear coupling circum-aural  circum-aural
Frequency response
(–10 dB referred to 1 kHz) 8 Hz — 25 kHz  8 Hz — 25 kHz
Sound pressure level 102 dB (as per IEC 268-7)  102 dB (as per IEC 268-7)
113 dB / 1 V
rms
 107 dB / 1 V
rms
Ambient noise attenuation max. 32 dB  max. 32 dB
THD < 0.1 % (at 51 kHz, 100 dB SPL)  < 0.1 % (at 1 kHz, 100 dB SPL)
Weight approx. 285 g  approx. 285 g
Contact pressure approx. 6 N  approx. 6 N
Length of coiled cable min. 1 m  min. 1 m
max. 3 m  max. 3 m
Frequency response curve
Diffuse field frequency response
HD 280 BDA 6.6.02 06.06.2002, 9:49 Uhr18
