Specifications
15 | HDVA 600
Specifications
Dimensions (W x H x D) approx. 224 x 44 x 306 mm
Weight approx. 2.25 kg
Max. output power approx. 480 mW @ 1 kHz and
600 load at the XLR-4 output
Frequency response < 10 Hz to > 100 kHz
Crosstalk attenuation min. 93 dB @ 1 kHz
THD+N < 0.001%
Gain
RCA input/XLR-4 output
adjustable
14 dB, 22 dB, 30 dB, 38 dB, 46 dB
Gain
XLR input/XLR-4 output 16 dB
Dynamic range >115 dB @ 600 load
(A-weighted)
Operating temperature range 0° – 45°C
Power supply
Voltage range 100 – 240 V ~, 50 – 60 Hz
Power consumption nom. 7 W
(2x 300 headphones connected
to the XLR-4 outputs)
max. 15 W
(2x 16 headphones connected to
the ¼“ (6.35 mm) jack outputs
RCA input
Max. input voltage 20 dBV (with minimum gain)
Impedance 10 k
XLR-3 input
Max. input voltage 18 dBV
Impedance 20 k
XLR-4 output
Pin assignment 1: L+, 2: L-, 3: R+, 4: R-, screen: GND
Impedance min. 16
¼“ (6.35 mm) headphone outputs
Pin assignment tip: left, ring: right, sleeve: GND
Impedance min. 16
