Sensus 461-S User Manual

6
Condensed Parts List
All Models
Illustration Part
Number Description Number
Valve Stem, stainless, for
091-00-016-07
12b
1” single seat assembly
Valve Stem, stainless, for
091-00-016-06
11/16” single seat assembly
Valve Retainer, brass, for 1”
091-16-018-03
double seat assembly (2 used)
Vale Retainer, brass, V Port
091-16-012-04
for 1” double seat (2 used)
12c
Valve Retainer, brass, for 11/16”
091-16-018-02
double seat (2 used)
Valve Retainer, stainless, for 1”
091-16-018-01
single or double seat (1 or 2 used)
Valve Retainer, stainless for 11/16”
091-16-018-00
single or double seat (1 or 2 used)
Molded Valve, Buna-N
(Black, 45-55 Duro) for 091-16-315-01
1” double seat all trim
Molded Valve, Buna-N
(Black, 45-55 Duro) for 11/16” 091-16-315-00
double seat all trim
Molded Valve, Polyurethane
(Red, 65-75 Duro) for 1” 091-16-315-11
double seat all trim
Molded Valve, Polyurethane
(Red, 65-75 Duro) for 11/16” 091-16-315-10
double seat all trim
Molded Valve, Viton
(65-75 Duro, stamped V) for 091-16-315-13
12d*
1” double seat all trim
Molded Valve, Viton
(65-75 Duro, stamped V) for 091-16-315-12
11/16” double seat all trim
Molded Valve, Polyurethane
(Red 65-75 Duro) for 1” 091-16-315-51
single seat
Molded Valve, Polyurethane
(Red 65-75 Duro) for 11/16” 091-16-351-50
single seat
Molded Valve, Viton
(65-75 Duro, stamped V) for 091-16-315-58
1” single seat
Molded Valve, Viton
(65-75 Duro, stamped V) for 091-16-315-57
11/16” single seat
Valve Locknut, brass, for
903920
double seat assembly
12e
Valve Locknut, stainless, for
920303
double seat assembly
Valve Locknut, 3/8" – 24 Crown
903936
Nylok, for single seat assembly
12f
Valve Stem Locking Ring,
091-16-043-01
stainless, for double seat assembly
*Minimum Recommended Spare Parts
Condensed Parts List
All Models
Illustration Part
Number Description Number
12g
Set Screw, slotted headless cup
907694
pt. #12-24 x 1/4” lg.
Female Valve Stem, brass, for
091-16-016-00
12h
double seat assembly
Female Valve Stem, stainless for
091-16-016-03
double seat assembly
Valve Guide, brass for
091-16-012-00
12j
double seat assembly
Valve Guide, stainless for
091-16-012-02
double seat assembly
12m
Roll Pin, 1/4” x 1-1/2” lg.,
910707
for single seat assembly
O-Ring 3/4” x 1” single
934015
12n*
seat assembly
O-Ring 9/16” x 3/4”, for
934011
11/16” single seat assembly
13
Guide Bushing, brass, with pin 091-16-385-02
Guide Bushing, stainless,with pin 091-16-385-03
14
Bottom Inspection Plate,Iron 091-16-004-01
Bottom Inspection Plate, Steel 091-16-004-02
15* Tetraseal (or O-Ring), 2-3/4” x 3” 904079
16
Cap Screws, Hex Hd.,
910030
5/16” - 18 x 1” lg.
Body, Screwed, 250 psi, Cast Iron 091-16-001-15
Body Flanged, ANSI 125,
091-16-001-17
FF, Cast Iron
17 Body Flanged, ANSI 250,
091-16-001-18
RF, Ductile Iron
Body Flanged, ANSI 300,
091-16-001-06
RF, Cast Steel
Outlet Orifice, 1” brass 091-16-029-01
18 Outlet Orifice 1” stainless 091-16-029-05
Outlet Orifice, 11/16” brass 091-16-029-00
Outlet Orifice, 11/16” stainless 091-16-029-04
Inlet Orifice, 1” brass 091-16-028-01
19 Inlet Orifice, 1” stainless 091-16-028-05
Inlet Orifice, 11/16” brass 091-16-028-0
Inlet Orifice, 11/16” stainless 091-16-028-04
20 Control Line Piping Assembly 091-16-361-50
20a 1/4” Sq. Hd. Steel Piping Plug 906055
20b 1/4” Malleable Iron Tee 946150
20c Nipple and Plug Assembly 091-00-361-50
Hex Hd. Steel Bolt,
5/16” - 18 x 1” lg. 910030
22 (461-12S, 461-8S, 461-S 12”)
Hex Hd. Steel Bolt,
5/16” - 18 x 1-1/4” lg. 910031
(461-S 8-1/2”)
23 Hex Steel Nut, 5/16” - 18 903859
26*
Tetraseal (or O-Ring),
904085
4-3/8” x 4-5/8”
27 Vent Cap, 1/4” 137-02-505-02
*Minimum Recommended Spare Parts
Installation and Maintenance Instructions
Model 461-S, 461-8S, and 461-12S Regulator
