Separett Tiny - Product Operation; Pre-Use Setup

10
Installation without visible urine hose
For installation without visible pipes, the 90-degree bend is used to guide the urine downwards or the
straight joint to go backwards as shown in the pictures below. Use the enclosed installation template to
make holes in the wall or oor in the correct positions.
Installation with visible urine hose
In cases where installation without visiblepipes is not possible, a 90 degree bend is used to install the urine
hose to the side (right or left) according to the pictures below.
If the urine hose is to be laid sideways and the toilet is to be installed against the wall,the urine hose must be
led through the side of the toilet,which requires a hole to be made in the plastic. For optimal results, use the
same drill you would use for making holes in the wall. The toilet has marks on either side to show where the
hole should be made, see pictures below. If you nd it difcult to drill from the inside, use a smaller drill to make
a small hole in the center, and then continue to drill from the outside. Use a knife or sandpaper to get a good
border.
If the urine hose is to be led further within the room, use the supplied Wall mount for urine hose.
Make sure that the urine hose has a downward inclination all the way and that you have read through the
recommendations for installing the urine hose.
