SeQual Eclipse 1000 - Alarm Conditions and Troubleshooting

WARNING AVAILABILITY OF AN ALTERNATE SOURCE OF OXYGEN IS
RECOMMENDED IN CASE OF POWER OUTAGE OR MECHANICAL
FAILURE. CONSULT YOUR PHYSICIAN FOR THE TYPE OF
BACK-UP SYSTEM REQUIRED.
DO NOT IGNORE ALARMS.
TYPICAL
CONDITIONS
UNIT NEEDS ATTENTIONSHUTDOWN CONDITIONS
The table shows possible alarm conditions and suggests appropriate responses. If any other alarms occur,
call your authorized SeQual dealer/provider.
Green Yellow Red Audible
Condition Indicator Indicator Indicator Alarm What to do
“Warming Up. Please Wait.” On On On None Wait. The system typically takes
3–5 minutes to reach specified
performance.
“2.0” (or flow setting) On Off Off None Nothing. The system is operating
properly at the specified flow rate.
“Low or Warm Power On Blinking Off Beeps Plug into external power or replace
Cartridge” with a charged Power Cartridge.
“O2 Concentration < 85%” Off Blinking Off None Continue Use. Check or clean air
intake filter. If condition persists,
contact dealer/provider.
“O
2
Concentration < 70%” Off Off Blinking Beeps Continue Use. Check or clean air
intake filter. If condition persists,
contact dealer/provider.
“Flow Rate Error/ Off Blinking Off Beeps Check tubing and/or humidifier
Blocked Flow” for obstruction. Check/clean
air intake filter. If condition
persists past 10 minutes,
contact dealer/provider.
“No Inspiration Detected” On On Off Beeps Make sure tubing does not
(in Pulse Flow Mode only) exceed 7 ft (2.1m) when using
Pulse Flow Mode. Audible alarm
will beep after 15 seconds if no
inspiration is detected. If no
inspiration detected 15 seconds
after that, the ECLIPSE will
automatically switch to
Continuous Flow Mode.
“Power Cartridge Shutdown Off Off Blinking On Seek external power source.
or hot Power Cartridge” (with If Power Cartridge malfunction
no external power present)
persists, contact dealer/ provider.
“Loss of External Power” Off Off Blinking On Seek an alternative oxygen
(without charged Power supply until external power is
Cartridge installed) restored or install a charged
Power Cartridge.
“System Malfunction” Off Off On On Contact dealer/provider. Use
bac
k up o
xygen supply
.
Alarm Conditions and Troubleshooting
30
|
ECLIPSE
TM
Model 1000 User Manual
