Serai CR/41 - Gate Movement Impulse Control; Impulse Sending Modes; Photocell;Sensitive Edge Entry; LED Indicator Meanings

DAL 1965
Pag.6/10
CR/41E
- A startimpulseduringtheopeningstopsthegate.
- Another impulse closes the gate.
STE-BY-STEP
FUNCTION
NOT ACTIVATED
DURING
OPENING
- A start impulse during the closig stops the gate for 2 sec. and
opens it automatically.
- A start impulse during the opening is not considered. A start
impulse during the pause with the gate opened closes the gate.
DURING
CLOSING
2s
start
start
start
start
DURING
OPENING
DURING
CLOSING
THESENDINGOF
ANIMPULSE
DURINGTHE
GATE
MOVEMENT
DIP-SWITCH
SET-UP
DESCRIPTION
FUNCTION
1 2 3 4 1 2 3 4
1 2 3 4 1 2 3 4
- A start impulse during closing stops the gate for 2 sec. and opens
it automatically.
2s
start
ENTRY
FOR
OPENING
PHOTOCELL
OR
SENSITIVEEDGE
1 2 3 4 1 2 3 4
1 2 3 4 1 2 3 4
- Function “sentive edge” activated: the entry to clamp 6 reverses the
motion of 10cm during opening or closing.
- Function “opening photocell” activated: the entry to clamp 6 stops
the motion during the opening, while reverses the motion during the
closing.
THEMEANINGOFEACHLED
LED
FINECH
FINE AP
FOTO AP
FOTO
STOP
PED
START
ON OFF
FUNCTION
Insidephotocell
Externalphotocell
STOP button
PEDESTRIANbutton
Open/Closebutton
OpeningPhotocellfree
ClosingPhotocellfree
STOP buttonnotpressed
Pedestrianbuttonpressed
Open/Closebuttonpressed
Correctconnectionof
8-10clamps
TheJumperon8-10clampsismissing
Fotocellula Aperturaoscurata
(presenzadiunostacolo)
FotocellulaChiusuraoscurata
(presenzadiunostacolo)
STOP buttonpressed
Pedestrianbuttonnotpressed
Open/Closebuttonnotpressed
DL10
Programming
Itisusedduringtheprogramming
DL8
MotorM2
Differentbrightnessaccordingto
thevoltagetothemotorM2
Nopower-supplytomotorM2
DL9
MotorM1
Differentbrightnessaccordingto
thevoltagetothemotorM1
Nopower-supplytomotorM1
Correctconnectionof9-10
clamps
TheJumperon9-10clampsismissing
STEP-BY-STEP
FUNCTION
ACTIVATED
SW2SW1
