CONTROL PANEL PROGRAMMING
Itisimportanttofollowcarefullystepbysteptheprogramming,ifmistakeshappenduringthisphaseitisnecessary
tomakeanewprogrammingfromthebeginning.
Toquittheprogrammingswitchonandoffthecontrolpanel.
Beforeproceedingwiththeprogrammingitisnecessarytocontrolthatallelectricalandsafetydevicesare
connected(push-button,photocells,flashinglight,etc...)
Checktheircorrectfunctionningandifnecessary:
AllLEDfortheNCentriesmustbe (stop,photocellsetc...)
AllLEDfortheentriesNOmustbe (start,pedestrian)
ON
OFF
A jumpermustbeplacedonthenormallyclosed(NC)entriesnotusedATTENTION:
PROGRAMMINGOFTHEWORKINGTIME ANDTHESLOW-DOWNFOR A DOUBLE-WINGGATE(DIP1SW1
OFF)
ControlpanelON,gateclosed.Pressonetimethebutton A (SET)toenterintoprogramming.LEDDL10starts
flashing. Theprogrammingphasebegins.
Pressonetimethepush-buttonB(BREAK)tomakemotorM2starting. Thetimethatyouwaitfromthebeginning
oftheopeningofM1andthepressingofB(BREAK)isthedelayofopeningofthesecondwing. Thistimeismax
15sec.Ifyoudonotpressanybuttonafter15sec. ThemotorM2startsautomaticallytheopening.
Whilethetwowingsareopening,adjustthepowerofthemotorturningthetrimmerPOWER.
ATTENTION:-ifthetrimmerPOWERissettwo“low”,thegatemaynotopen.Wesuggesttomakethis
settingstartingwiththetrimmerturnedtotheMAXIMUManddecreasingthepowerwhilethewingis
opening.
-Thehighdifferencesoftemperaturebetweensummerandwintercausedifferent
expansionsinallmaterials,includingthematerialofourproducts.Forthis
reasonwerecommendtocontrolthemotorforceadjustingeachwinterand
summerinthebeginnigofeachseason.
ATTENTION: - If you want to change some of the above adjustment it is necessary to repeat
the programming from the beginning.
- During programming the slow-down is set only in the closing phase but
During the standard working it is used also in the opening phase.
Pressonetimepush-buttonC(WORK):themotorM1startstheopening(M2remainsstill).
WhenthewingofmotorM1arrivesagainstthestopblockswaitfor3-4secondsandafterpressonetimebutton
C(WORK).MotorM1switchesOFF.
WhenthewingofmotorM2arrivesagainstthestopblockswaitfor3-4secondsandafterpressonetimebutton
C(WORK).MotorM2switchesOFF.
Whenthetwowingsarecompletelyopenandthemotorsarenotsupplied,pressonetimebuttonB(BREAK)to
starttheclosingphaseofmotorM2(M1remainsstill).
Pressonetimethepush-buttonC(WORK)tomakealsomotorM1starting. Thetimethatyouwaitfromthe
beginningoftheclosingofM2andthepressingofC(WORK)isthedelayofclosingofthewing. Thistimeis
max15sec.Ifyoudonotpressanybuttonafter15sec. ThemotorM1startsautomaticallytheclosing.
Duringtheclosing,pressB(BREAK)whenyouwantthatthemotorM2startstheslow-down(wesuggestat
least fromthestopblocks).MotorM2startstheslow-down.50cm ATTENTION:DONOTconsiderthispointif
theslow-downisnotactivated(DIP2SW2ON)
Duringtheclosing,pressC(WORK)whenyouwantthatthemotorM1startstheslow-down(wesuggestat
least fromthestopblocks).MotorM1startstheslow-down.50cm ATTENTION:DONOTconsiderthispointif
theslow-downisnotactivated(DIP2SW2ON)
WhenthewingofmotorM2arrivesagainstthestopblockswaitfor3-4secondsandafterpressonetimebutton
B(BREAK)MotorM2switchesOFF.
WhenthewingofmotorM1arrivesagainstthestopblockswaitfor3-4secondsandafterpressonetimebutton
C(WORK).MotorM1switchesOFFandcontrolpanelquitautomaticallyfromprogramming.Itisreadyfor
functionning.
