Serai CR/41 - Specific Gate Programming; Single-Wing Gate Programming; Automatic Reclosure Settings

DAL 1965
Pag.8/10
CR/41E
ControlpanelON,gateclosed.Pressonetimethebutton A (SET)toenterintoprogramming.LEDDL10starts
flashing. Theprogrammingphasebegins.
Whilethewingisopening,adjustthepowerofthemotorturningthetrimmerPOWER.
ATTENTION:-ifthetrimmerPOWERissettwo“low”,thegatemaynotopen.Wesuggestto
makethissettingstartingwiththetrimmerturnedtotheMAXIMUMand
decreasingthepowerwhilethewingisopening.
-Thehighdifferencesoftemperaturebetweensummerandwintercausedifferent
expansionsinallmaterials,includingthematerialofourproducts.Forthis
reasonwerecommendtocontrolthemotorforceadjustingeachwinterand
summerinthebeginnigofeachseason.
ATTENTION: - If you want to change some of the above adjustment it is necessary to repeat
the programming from the beginning.
- During programming the slow-down is set only in the closing phase but
during the standard working it is used also in the opening phase.
Pressonetimepush-buttonC(WORK):themotorM1startstheopening.
WhenthewingofmotorM1arrivesagainstthestopblockswaitfor3-4secondsandafterpressonetimebutton
C(WORK).MotorM1switchesOFF.
Whenthewingiscompletelyopenandthemotorisnotsupplied,pressonetimebuttonC(WORK)tostartthe
closingphase.
Duringtheclosing,pressC(WORK)whenyouwantthatthemotorM1startstheslow-down(wesuggestat
least fromthestopblocks).MotorM1startstheslow-down.50cm ATTENTION:DONOTconsiderthispointif
theslow-downisnotactivated(DIP2SW2ON)
WhenthewingofmotorM1arrivesagainstthestopblockswaitfor3-4secondsandafterpressonetimebutton
C(WORK).MotorM1switchesOFFandcontrolpanelquitautomaticallyfromprogramming.Itisreadyfor
functioning.
PROGRAMMINGOFTHEPAUSETIMEWITHOPENGATE(AUTOMATICRECLOSURE)
ControlpanelON,gateclosed.Pressonetimethebutton A (SET)toenterintoprogramming.LEDDL10
startsflashing. Theprogrammingphasebegins.
PressonetimeB(BREAK)-flashinglightON-thecontrolpanelstartstocountthetimeforthepause
whenthegateisopen,oneflashing=1second.
PressB(BREAK)whenyouwanttofixthetimechoosenforthepause,thecontrolpanelmemorizethe
timefromthefirstandthesecondpressingofB(BREAK).
Itquitautomaticallyfromprogramming.
Ifyoudonotpressanybutton,afterthemaximumtimeof120sec.thecontrolpanelquittheprogramming
memorising120sec.
ACTIVATE THE AUTOMATICRECLOSURE(MAX120sec.)
PressandkeeppressedB(BREAK)untilLEDDl10switchesOFF.
Controlpanelquitautomaticallyfromprogramming.
Theautomaticreclosureisdeactivated.
DEACTIVATE THE AUTOMATICRECLOSURE
ControlpanelON,gateclosed.Pressonetimethebutton A (SET)toenterintoprogramming.LEDDL10
startsflashing. Theprogrammingphasebegins.
PROGRAMMINGOFTHEWORKINGTIME ANDTHESLOW-DOWNFORGATEWITHONLY ONEWING(DIP1SW1ON)
