Serai CR/41 - Transmitter Code Learning; Transmitter Compatibility; Learning Start Code; Learning Pedestrian Code

LEARNINGOFTRANSMITTERCODE
Thecontrolpanelhasanincorporatedtwo-channelreceiverat433,92Mhzwhichallowstoremotelydrivethegate
throughtransmittersatdip-switches-OG/02andOG/04-andalsoself-learningtransmittersOG/62,OG/64,
OG/52,OG/54,OG/82/1andOG/84. Thefirstchannelofthereceiverworkslikeastart,whilethesecondchannel
workslike“pedestrian”start.
ERASINGOFTHESTOREDCODES
Keeppressedthebutton A (SET)forabout10sec.UntiltheLEDDL10switchesoff.
!
ATTENTION: -beforeusingatransmitter,itiscompulsorytoprogramit
-themaxnumberofcodesis32fortheSTARTfunctionand32forthe
PEDESTRIANfunction(differentcombinationarenotpossible:forex.40start+24
pedestrianNOTPOSSIBLE).
Someexamplesofthepossiblecombinations:
32self-learningtransmitters-example A: OG/62,OG/64,OG/28,OG/48, OG/52,
OG/54,OG/82/1orOG/84as (forex.theleftpush-button)+
OG/62,OG/64,OG/28,OG/48,OG/52,OG/54,
OG/82/1orOG/84as (forex.therightpush-button)
-exampleB: OG/62,OG/64,OG/28,OG/48,OG/52,
OG/54,OG/82/1orOG/84as (forex.theleftpush-button)+
OG/02,OG/04as (itisnotnecessarytoprogram
theotherOG/02orOG/04sinceitisenoughtosetthedip-switchesinthe
sameposition)+ OG/62,OG/64,OG/28,
OG/48,OG/52,OG/54,OG/82/1orOG/84as (forex.theright
push-button)+ OG/02,OG/04as (it
isnotnecessarytoprogramtheotherOG/02orOG/04sinceitisenough
tosetthedip-switchesinthesameposition)
start 32self-
learningtransmitters
pedestrian
31self-learningtransmitters
start 1dip-
switchtransmitter start
31self-learningtransmitters
pedestrian
1dip-switchtransmitter pedestrian
!
DAL 1965
Page9/10
LEARNINGOF THESTART CODE
-ControlpanelON,gateclosed. thebutton A (SET)toenterintoprogramming.LEDDL10starts
flashing. Theprogrammingphasebegins.
-Pressthebuttoninthetransmitter(forex.theleftbutton)andkeepitpresseduntilLEDDL10switchesOFF. The
controlpanelhasmemorisedthecodeanditquitautomaticallyfromprogramming.
-Repeatthesamestepifyouneedtoprogramothertransmitters.
Pressonetime
LEARNINGOF THEPEDESTRIANCODE
-ControlpanelON,gateclosed. thebutton A (SET)toenterintoprogramming.LEDDL10starts
flashing. Theprogrammingphasebegins.
- thebutton A pressthebuttoninthetransmitter(forex.therightbutton)andkeepthempressed
untilLEDDL10switchesOFF. Thecontrolpanelhasmemorisedthecodeanditquitautomaticallyfrom
programming.
-Repeatthesamestepifyouneedtoprogramothertransmitters.
Pressonetime
Keepingpressed
12 3 4
5
6 7
8
9
10
12 3 4 5 6 7 8 9 10
!
CHANGETHEFACTORY SET-UP
TO AVOIDNOTWANTEDDRIVES
DIP-SWITCHSET-UP ONLY FOR TRANSMITTERSOG/02 ANDOG/04
Onlyintheeventthatthedip-switchestransmittersOG/02orOG/04areused,itisnecessarytochangethedip-
switchset-upbeforetheprogramming,inordertochangethefactoryset-up.
ATTENTION: beforeproceedingwiththeprogrammingortheerasingofthetransmittersitis
necessarytodisconnecttemporarilytheantennatoavoidthatthereceiverduringthesephases
acquiresothersignalswhichmaycausetheuncorrectfunctionningofthesystem.
Connecttheantennaassoonasfinished.
CR/41E
