BlueSnap Commands Version 4.81SIO, 1/20/2016 Page 23 of
27
Cedar Park, TX, USA • (512) 994-3630 • sales@serialio.com www.serialio.com
Below are Internal Jumper options for BlueSnap Standard (Female) and BlueSnap 9V (Female)
(internal jumpers for Male DB9 versions are different, see prior page)
DCE 3 Wire Factory Default (CTS shorted to RTS),
Remove 3
rd
, 4
th
jumpers and one jumper in position 5
DTE (Like a PC) RX=2, TX=3, RTS=7, CTS=8
