Serta Executive Chair - Step 2: Attach Seat Plate

Step 2
Attach Seat Plate (D) to the bottom of the Seat Cushion (F)
(with the front of the seat plate facing the front of seat cushion).
Attach by using 1-5/8” Screws (I) for the front holes of the Seat
Plate (D) and 7/8” Screws (H) for the rear holes of the Seat Plate
(D) with the Allen Key (M).
*Note: Align the Seat Plate so the FRONT on the seat plate
matches the FRONT label on the bottom of the seat cushion.
Tighten the screws completely.
8
I
H
M
F
D
