CDHD2

Operator Panel (HMI) 25

Motor Setup

Code

C0001

Command

Motor Setup

VarCom

MOTORSETUP

Sequence

Make sure the drive is disabled, and has no faults

Select: C0001

Press: Shift

Display: nnset

Press: Long Shift

Display: Motor setup progress in % number

Done: done

(or an error code)

Clear Faults OK

Code

C0002

Command

Clear Faults

VarCom

CLEARFAULTS

Sequence

Select: C0002

Press: Shift

Display: 00000.

Press: Shift

Display: Flashing 0. in digit 1

Press: Long Shift

Display: 00000.

or will continue to show the fault code
