CDHD2
Operator Panel (HMI) 33
Actual Speed
Shows the actual speed of the motor, as measured by the primary
feedback, in rpm.
Speed is shown in digits 4 3 2 1
If motion is in a negative direction, DP5 is lit.
Press: Shift
Display: 00000
Press: Shift (repeatedly), until only DP1 is lit.
Start motion.
0 0 2 5 0. = positive motion 250 rpm
0 0 0 2 0. = positive motion 20 rpm
0.0 2 5 0. = negative motion 250 rpm
0.0 0 2 0. = negative motion 20 rpm
Actual Position (degrees)
Actual Position, in degrees
Shows the actual position of the motor, as measured by the primary
feedback, in degrees.
If the position is a negative value, DP5 is lit.
Press: Shift (repeatedly) until only DP2 and DP1 are lit.
Start motion.
Press the Shift key to view the next string.
0025.0. during motion
0036.0. (move absolute 36,000 degrees position: 100 revs.)
0360.0. (move absolute 360,000 degrees position: 1000 revs.)
1800.0. (move absolute 1,080,000 degrees position: 3000 revs.)
0.003.6. (move absolute -3,600 degree position: -10)
