CDHD2
34 Operator Panel (HMI)
Actual Position (rev)
Actual Position, in revolutions
Shows the actual position of the motor, as measured by the primary
feedback, in revolutions.
If the position is a negative value, DP5 is lit.
Press: Shift
Start motion.
If number of revolutions = 1000 – 9999:
digits 4 3 2 1 = integer value
If number of revolutions <1000:
digits 4 3 2 = integer value,
digit 1 = decimal value
DP1 is lit
If number of revolutions <100
digits 4 3 = integer value
digits 2 1 = decimal value
DP2 and DP1 are lit
If number of revolutions <10
digit 4 = integer value
digit 3 2 1 = decimal value
DP3, DP2 and DP1 are lit
If number of revolutions > 10,000, press Shift to view the next string.
If position = 00.000 to 99.999:
String 1:
78.123. 78.123 revolutions
97.345 97.345 revolutions
If position = 100.000 to 999.999:
String 1:
01.789. = 101.789 revolutions
04.367. = 104.367 revolutions
Press Shift
String 2:
0000.1. = 101.789
