SET SET-2010 - Page 7

7 of 10
www.smart-e-tech.com
SET-2010
Technical Description
Issue 02 13/04/2022
Row
e
d
c
b
a
1
P0.0- / P4.0-
P0.0+ / P4.0+
NC
P0.1- / P4.1-
P0.1+ / P4.1+
2
P0.2- / P4.2-
P0.2+ / P4.2+
NC
P0.3- / P4.3-
P0.3+ / P4.3+
3
GND
GND
GND
GND
GND
4
P1.0- / P5.0-
P1.0+ / P5.0+
NC
P1.1- / P5.1-
P1.1+ / P5.1+
5
P1.2- / P5.2-
P1.2+ / P5.2+
NC
P1.3- / P5.3-
P1.3+ / P5.3+
6
GND
GND
GND
GND
GND
7
P2.0- / P6.0-
P2.0+ / P6.0+
NC
P2.1- / P6.1-
P2.1+ / P6.1+
8
P2.2- / P6.2-
P2.2+ / P6.2+
NC
P2.3- / P6.3-
P2.3+ / P6.3+
9
DGND
DGND
DGND
DGND
DGND
10
P3.0- / P7.0-
P3.0+ / P7.0+
NC
P3.1- / P7.1-
P3.1+ / P7.1+
11
P3.2- / P7.2-
P3.2+ / P7.2+
NC
P3.3- / P7.3-
P3.3+ / P7.3+
12
NC
NC
NC
NC
NC
13
NC
NC
NC
NC
NC
14
NC
NC
NC
NC
NC
15
P4.0- / P0.0-
P4.0+ / P0.0+
NC
P4.1- / P0.1-
P4.1+ / P0.1+
16
P4.2- / P0.2-
P4.2+ / P0.2+
NC
P4.3- / P0.3-
P4.3+ / P0.3+
17
GND
GND
GND
GND
GND
18
P5.0- / P1.0-
P5.0+ / P1.0+
NC
P5.1- / P1.1-
P5.1+ / P1.1+
19
P5.2- / P1.2-
P5.2+ / P1.2+
NC
P5.3- / P1.3-
P5.3+ / P1.3+
20
DGND
DGND
DGND
DGND
DGND
21
P6.0- / P2.0-
P6.0+ / P2.0+
NC
P6.1- / P2.1-
P6.1+ / P2.1+
22
P6.2- / P2.2-
P6.2+ / P2.2+
NC
P6.3- / P2.3-
P6.3+ / P2.3+
23
GND
GND
GND
GND
GND
24
P7.0- / P3.0-
P7.0+ / P3.0+
NC
P7.1- / P3.1-
P7.1+ / P3.1+
25
P7.2- / P3.2-
P7.2+ / P3.2+
NC
P7.3- / P3.3-
P7.3+ / P3.3+
XJ2 Connector Pin Assignments
Signal
Description
Px.y
Line y in Port x
GND
Ground connection
NC
No connection
XJ2 Connector Signal Descriptions
