This document is the user manual for the SetPower RV Dual Zone Series portable refrigerator/freezer, available in two models: RV45D and RV60D.

Function Description:

The SetPower RV Dual Zone Series is a portable refrigerator/freezer designed for use in RVs and similar applications. It features a dual-zone design, allowing for independent temperature control of two compartments, although it can also function as a single-zone unit if the internal divider is removed. The device is intended for cooling and freezing food and beverages. It operates on both DC (12V/24V) and AC (110V-240V) power sources, making it versatile for various power setups. The unit is equipped with a compressor-based refrigeration system and includes features like battery protection settings to prevent over-discharge of the power source.

Important Technical Specifications:

Models: RV45D, RV60D
External Dimensions:
- RV45D: 25.4 × 16.7 × 17.3 inches (645 × 425 × 440 mm)
- RV60D: 25.4 × 16.7 × 21.1 inches (645 × 425 × 535 mm)
Capacity:
- RV45D: 45 Qt / 43 L
- RV60D: 60 Qt / 56 L
Net Weight:
- RV45D: 38 lbs (17.2 kg)
- RV60D: 41 lbs (18.8 kg)
Rated Power Consumption: 60W for both models
Temperature Range: -18°C to +10°C (0°F to 50°F)
Power Source: DC 12V/24V, AC 110V-240V
Rated Current: 5A / 2.5A
Fuse: 15A
Warranty: 3-year warranty for the compressor, 1-year warranty for other accessories.

Usage Features:

Control Panel: The device features a user-friendly control panel with a power button, temperature adjustment buttons for each compartment (left and right), and a set button. Gauges display the current temperature settings.
Dual Zone Operation: The refrigerator has two compartments with independent temperature controls. The left compartment's default target temperature is 0°F, and the right compartment's default is 41°F.
Temperature Adjustment: Users can adjust the target temperature for each compartment using the '+' and '-' buttons. Holding the button accelerates the adjustment process.
Max/Eco Mode: The 'Set' button toggles between Max (Fast Cooling) mode, indicated by a blue light, and Eco (Energy Saving) mode, indicated by a green light.
Battery Protection Settings (Pr): In stand-by mode, pressing and holding the '+' and '-' buttons for the right compartment for 3 seconds allows access to the settings menu. The 'Power' button toggles between Battery Protection Settings (Pr) and °C/°F Settings (CF). There are three battery protection levels: High (==), Mid (==), and Low (--). The default is Mid. This function prevents over-discharge of the battery by shutting off the compressor if the DC voltage drops below a set cut-off value.
Temperature Unit Switch (°C/°F Settings - CF): Users can switch between Celsius and Fahrenheit display using the '+' or '-' buttons when "CF" is shown on the right gauge.
Divider Removal: The internal divider can be removed to convert the unit into a single-zone refrigerator, making only one temperature setting available. Note that removing or installing the divider resets the target temperature to its default value.
Pre-cooling: It is recommended to pre-cool the empty unit before use to enhance system efficiency.
Error Codes: The manual provides a list of error codes (E1-E6) and their corresponding solutions, such as low input-voltage, fan error, motor start error, minimum motor speed error, ambient temperature error, and thermal sensor fault. Solutions often involve checking battery protection settings, recharging the battery, or contacting customer support.

Maintenance Features:

Cleaning: The unit should be powered off and unplugged before cleaning. Non-abrasive detergent should be used for cleaning the interior and exterior.
Defrosting: The unit should be defrosted when ice forms on the internal walls or lid. Users are advised not to scrape the interior to defrost or de-ice.
General Care: Avoid pressure-washing or spraying the fridge with a running water hose.
Energy Saving Tips:
- Place the unit on a dry, secure surface with adequate ventilation.
- Ensure the lid is closed and secure, and only open it when necessary.
- Cool down hot/warm food before placing it in the unit.
- Defrost the unit when ice builds up.
- Select the proper target temperature for the specific need.
Safety Instructions:
- Do not expose to heavy rain.
- Avoid direct heat sources.
- Do not place open liquid containers inside.
- Secure contents before using in a moving vehicle.
- Do not use unapproved electrical devices inside.
- Do not store explosive items.
- Avoid touching the compressor or condenser when operating.
- Ensure the supply cord is not trapped or damaged.
- Do not immerse in water or use in excessively muddy areas.
- Do not stand on the cooler.
- For disposal, remove doors and leave shelves in place to prevent child entrapment.
