SevenStar D07–60B - 2 Specification

Page 2 of 26
2. SPECIFICATION
Table 1. Specifications of D07-60B MFC and D07-60BM MFM
NO
Item
D07-60B
D07-60BM
1
Flow Ranges
300，500，750，1000，1500，2000SLM
2
Accuracy
± 2% F.S.
3
Linearity
±1% F.S.
4
Repeatability
±0.2%F.S.
5
Response-Time
＜ 10 sec
6
Operation
Pressure
(0.25 ~ 0.5) MPa （≤1000SLM）
(0.4 ~ 0.6) MPa （＞1000SLM）
＜0.2 MPa
7
Max Pressure
3 MPa
8
Operation
Temperature
5~ 45 ℃
9
Input Signal
0 ~ 5.00 V (Input Resistance > 500K)
NO
10
Output Signal
0V ~ 5.00 V (Output Electric Current ≤3mA)
11
Valve Type
N.C. Solenoid
NO
12
Power Supply
+15V 50 mA
-15V 200 mA
+15V 50 mA
-15V 50 mA
13
Dimension (mm)
According to Figure 3a、3b、3c、3d
14
Weight (kg)
6
5
Notes :
MFC/MFM is calibrated by N
2
as a standard gas.
Units: SCCM (Standard Cubic Centimeter/Min);
SLM (Standard Liter/Min)
Standard Situation: Tem — 273.15K ( 0 ºC );
Air Pressure — 101325 Pa (760mm Hg)
For Sevenstar MFC/MFM, the unit of SCCM is identical to “mL/min, 0 ºC ,1atm”, and the unit of SLM
