- 25 -
Change the Door Stop
• If necessary, the door can be changed from right-
to left-hinged.
• Warning! Before you work on the appliance,
always pull the mains plug out of the point.
• In order to avoid damages to persons and prop-
erty, execute the change of the door stop with
two persons.
• We recommend leaving the change of the door
stop to experts.
• Beforeyoustartwiththemodications,hereis
some general info:
ū Always pay attention to the number of shims
on the bearing pins and screws.
ū Position the doors always so that they close
tightly.
Step 1
a) Loosen the screw from the cover of the hinge
and remove the cover (pictures similar to prod-
uct).
b) Unscrew the 4 screws that hold the upper hinge
and remove it.
c)Loosen2screwsasshowninthegurebelow,in
order to remove the gap caver on the top side of
the appliance.
d) Raise the refrigerator door about 50 mm, in
order to remove it from the appliance.
