Correct
When installed correctly, the T-bar should
point away from the curved table edge
Incorrect
If T-bar is angled toward the curved edge,
the installation is backwards and will slant
Step 4. Install Top
Insert assembled top into frame neck with
curved edge facing toward user. Install
tension knob (L) to secure height.
IMPORTANT: Tighten the locking screw
against the T-bar to prevent the desk from
moving up and down by turning the tension
knob (L) clockwise until snug. Turn counter-
clockwise until loose to adjust desk height.
Step 5. Complete!
Congratulations! Your desk is ready to use.
IMPORTANT: If the desk top is slanted,
remove it from assembly, rotate 180
degrees and reinsert.
