•The SANISHOWER
®
requires
230/240V. AC single phase 50HZ
supply (UK specification) and
should be connected to an
unswitched fixed wire connector
fitted with a 5-amp fuse or circuit
breaker.
• The SANISHOWER
®
should be
installed 60cm. Minimum from the
shower tray, or should be separated
from it with a fixed panel. It should
not be possible to splash the
SANISHOWER
®
in normal use.
•The mains lead wiring colour code
is as follows:
BROWN = LIVE
BLUE = NEUTRAL
GREEN/YELLOW = EARTH
CONNECTION OF INLET
Connect the wider end of the flexible
connector A to the SANISHOWER
®
side inlet. The other end should be
connected to the 40mm waste pipe
from the shower tray. Use the plastic
"Herbie" clips B. Tighten clip B with a
pair of pliers.
WARNING: When connecting a shower
please make sure that the underside of
the shower tray is at least 6 cm above
floor level.
INSTALLATION UNDERNEATH
THE SHOWER TRAY
INSTALLATION
This type of installation should only be
carried out by a qualified person.
The shower tray must be raised so as
to allow 145mm to accommodate the
SANISHOWER
®
.
WARNING: It is important that an
access panel of minimum length
400mm and height 145mm is
provided for possible maintenance
of the unit.
A screwdriver or other tool should
be required to open the access
panel.
ELECTRICAL INSTALLATION
The electrical installation should be
carried by a qualified person. All
wiring must conform to BS7671 1992 -
Requirements for electrical installation.
•The SANISHOWER
®
requires
230/240V. AC single phase 50HZ
supply (UK specification) and
should be connected to an
unswitched fixed wire connector
fitted with a 5-amp fuse or circuit
breaker.
7b
DESCRIPTION
SANISHOWER
®
is a special domestic
pump designed to take the waste from a
shower and wash basin. Its compact size
and low activation level make it ideal for
installation next to or under a shower tray
(as long as it is accessible for possible
maintenance).
Installed correctly, it will give consistent,
reliable service.
Please note the following warning signs:
Possible danger to personnel
Warning of possible electrical hazard
WARNING: This is a general warning that
failure to follow instructions could result in
poor functioning of the unit.
TECHNICAL DATA
SANISHOWER
®
Application 1 Shower and
1 Washbasin
Vertical Pumping Max 4 m
Horizontal Pumping Max 50 m
Nominal Power Rating 250 W
Medium Water Temperature 35°C
Electric Class I
Type D60
Noise Level 40dBA
Net Weight 3,5 KG
LIST OF ACCESSORIES INCLUDED:
Refer to drawing.
DIMENSIONS: Refer to drawing.
PERFORMANCE CURVE: Refer to
graph.
VERTICAL/HORIZONTAL PUMPING
COMBINATIONS: Refer to drawing.
INSTALLATION
2 types of installation are possible with
SANISHOWER
®
• Installation next to the shower tray.
•Installation underneath the shower tray.
Please follow the relevant sections 7a or 7b
below.
INSTALLATION NEXT TO THE
SHOWER TRAY
ELECTRICAL INSTALLATION
The electrical installation should be carried
by a qualified person. All wiring must
conform to BS7671 1992 - Requirements
for electrical installation.
7a
1
2
3
4
5
6
7
GB
04/98
