12. TROUBLESHOOTING GUIDE
Oil does not come out
13. TECHNICAL SPECIFICATIONS
Power Unit
Displacement 62cc
Fuel Mixture Petrol 25 : Two Stroke Oil 1
Fuel tank capacity 550 cm3
Engine oil SAE10W30
Oil tank capacity 260 cm3
Carburettor Diaphragm type
Ignition system Pointless (CDI)
Spark plug NGK L7T
Oil feeding system Automatic pump
Sprocket 7T x 0.325”
Dimensions 400 L x 250 W x 290 H (mm)
Dry weight 6.0 kg
Cutting Head
Guide bar type Sprocket nose
Guide bar size 18” (450mm), 20” (500mm)
Saw chain pitch 0.325”, 8.26mm
Saw chain gauge 0.058”, 1.27mm
Power 2.4/8,500 (kw/min)
Max speed 12,000 rpm
Idle speed 3000 rpm
