SPECIFICATION
Lifting capacity position 1 1000kg
Lifting capacity position 2 750kg
Lifting capacity position 3 500kg
Lifting capacity position 4 250kg
Maximum lifting height min. jib ext. 2020mm
Maximum lifting height max. jib ext. 2248mm
Length of jib position 1 902mm
Length of jib position 2 990mm
Length of jib position 3 1080mm
Length of jib position 4 1168mm
Height of frame 159mm
Length of frame 1251mm
Overall height 1400mm
Width of frame max 952mm
Distance between centre of rear wheels 597mm
WARNING
Do not overload. Overloading could cause damage or failure of the crane. Never exceed
the safe working loads indicated on the jib.
Never use the crane on an uneven floor surface as this could result in the crane tipping
over.
Always lock the legs and jib in position before lifting a load.
The nuts and bolts supplied with the crane are all high strength and should not be sub-
stituted for inferior types. Before each use ensure that all nuts and bolts are correctly
fitted and tight.
