11
D
A
B
C
DISMANTLING
The internal textile parts are completely
knockdown :
1. Return your helmet.
2. Separate both parts of the chin strap.
3. Remove the neck pad by holding one of its
sides, then the other (Fig. A).
4. Pull out the end and then detach its rear
section in order to remove it from its housing
(Fig. B).
5. To complete the operation, unclip the front of
the head section, starting with one side (Fig. C)
and remove the head section.
6. Drop out both cheeks (Fig. D).
