19
Fig. 28
Fig. 28
Fig. 29
Fig. 28
Fig. 30
V E N T S
ENGLISH
CLOSED
OPEN
CLOSED
OPEN
VENTILATION SYSTEM
The ventilation system of the helmet
consists of:
LOWER VENTILATION
It allows ventilation around the mouth
area and conveys the air directly on the
visor, thus reducing fogging.
See Fig.28 for opening and closing ope-
rations.
TOP VENTILATION
It provides direct ventilation to the head
upper area, even at low speed.
See Fig.29 for opening and closing ins-
tructions.
REAR VENTILATION
It allows warm and stale air to flow out,
thus ensuring an optimum comfort inside
the helmet (Fig.30).
SETTING UP THE N-COM - HELMET
COMMUNICATION SYSTEMS
(Available as standard or accessory/spare part)
Your helmet is factory-preset to be equip-
ped with the N-Com communication sys-
tem.
If your helmet is homologated according
to ECE/UN Regulation No. 22, it has also
been tested and homologated with the
N-Com system installed. Installing a sys-
tem other than the N-Com affects the
helmet’s regulatory compliance. During
the communication system installa-
tion (see the specific instructions in the
N-Com kit), it will be necessary to remove
from the helmet the foam material fillers
located in the polystyrene cheek pads
next to the N-Com earphones housings.
The above-mentioned fillers should only
be removed if the helmet is used with a
compatible N-Com system installed.
