11
SUN VISOR
SHARK Nano ONLY
RemOVal assembly
1. Move the sun visor in the lowered position
(Fig 1)
2. Pull the sun visor down gently (Fig 2)
3. Unclip the sun visor sideways (Fig 3)
Same operations are reverse
1. Move the joystick sun visor in the down
position (Fig 4)
2. Clip sideways sun visor on one side then the
other (Fig 5)
3. Then clip the sun visor by lifting slightly
(Fig 6)
1
4
2
5
3
