9
QRVS SYSTEM
QRVS System
SHARK Nano ONLY
This screen has a system of easy disassembly
without tools, allowing you to clean it easily.
1. Claim screen in the upper position (Fig 1)
2. Exerting tension on the side of the screen
(Fig 2)
3. Then repeat on the other side (Fig 3)
1
2
3
Dismantling
assembly
1. Place the screen face to the helmet (Fig 4)
2. Screen the hooks in the side flanges (Fig 5)
3. Squeeze homogeneous on both sides (Fig 5)
4
5
