M25
To load a configuration file, proceed as follows:
• Click on “Load”. A new window will appear
• Select the desired file and then click “Open”
• The configuration has now been loaded
Through these steps, multiple configurations can be saved and loaded. The box “About” displays the program
version.
Device Active/Deactivated
At this point, the 7.1 Sound Extension status is displayed. If “Device Deactivated” appears in red text, the
X-Rest 7.1 is not detected. In this situation, please check the USB connection on your motherboard. “Device
Active” in green text means that the device is found and now ready for use.
EQ (on/off)
Click here to turn the equalizer on/off. When the equalizer is active, the field is highlighted blue.
3D (on/off)
Click here to turn the 3D effect on/off. When 3D is active, the field is highlighted blue.
Reset
Click here to reset the equalizer within the currently selected profile back to the default setting.
Profiles 1 – 4
Select the desired profile here. Changes
always affect the currently selected
profile.
Adjust the sound by using the 5-band
equalizer. To do this, using your mouse,
move the slider either up or down. The
following frequencies are available: 60,
300, 1200, 3600 and 12000 Hz.
Virtual 7.1
Under “Virtual 7.1” each of the eight
virtual speakers can be individually re-
positioned. To do so, click on the desired
speaker and then drag it into position.
To test the room effect, rotate the selec-
ted configuration either clockwise or
counterclockwise. To do this, click on
the corresponding arrow above the
graph. Music or sound effects played
are adjusted based on where the spea-
kers were placed. Click “Reset” to res-
tore back to default configuration.
C
B
D
E
F
