Sharp 13N-M100 Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
23
13N-M100/150
CN13M10
PWB-A: DUNTKA055WEV6 (13N-M100/150)
PWB-A: DUNTKA055WEV8 (CN13M10)
MAIN UNIT (Continued)
Q752 VS2SC945AQ/-1 J 2SC945AQ AB
or
VS2SC3198-Y-1
Q753 VS2SA1013//1E J 2SA1013 AD
Q2010 VS2SC3928R/-1 J 2SC3928R AB
Q2060 VS2SC3928R/-1 J 2SC3928R AB
Q2201 VS2SC3928R/-1 J 2SC3928R AB
Q2211 VS2SC3928R/-1 J 2SC3928R AB
DIODES
D52 RH-EX0676GEZZ J Zener Diode, 32V AA
D454 RH-EX0103CEZZ J Zener Diode, 5.6V AB
D455 RH-DX0475CEZZ J Diode AB
D456 RH-DX0475CEZZ J Diode AB
D457 RH-EX0644GEZZ J Zener Diode, 13V AB
D458 RH-EX0644GEZZ J Zener Diode, 13V AB
D459 RH-DX0475CEZZ J Diode AB
D491 RH-EX0630GEZZ J Zener Diode, 5.1V AA
D492 RH-EX0630GEZZ J Zener Diode, 5.1V AA
D493 RH-EX0630GEZZ J Zener Diode, 5.1V AA
å D502 RH-DX0131CEZZ J Diode AC
D510 RH-EX0654CEZZ J Zender Diode AD
D511 RH-DX0441CEZZ J Diode AC
D601 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ J AD
D603 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D610 RH-DX0131CEZZ J Diode AC
D641 RH-EX0630GEZZ J Zener Diode, 9.1V AA
çå D651 RH-DX0131CEZZ J Diode AC
çå D653 RH-EX0667GEZZ J Zener Diode, 27V AA
å D661 RH-DX0229CEZZ J Diode AF
å D701 RH-DX0490CEZZ J Diode AC
or
RH-DX0154CEZZ
å D702 RH-DX0490CEZZ J Diode AC
or
RH-DX0154CEZZ
å D703 RH-DX0490CEZZ J Diode AC
or
RH-DX0154CEZZ
å D704 RH-DX0490CEZZ J Diode AC
or
RH-DX0154CEZZ
D754 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D755 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
å D756 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D757 RH-DX0475CEZZ J Diode AB
å D758 RH-DX0131CEZZ J Diode AC
å D760 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
å D762 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
å D763 RH-DX0475CEZZ J Diode AB
å D765 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D2001 RH-DX0475CEZZ J Diode AB
PACKAGED CIRCUITS
å PR701 RMPTP0026CEZZ J Packaged Circuit AF
X801 RCRSB0001PEZZ R Crystal AL
or
RCRSB0205CEZZ
FILTERS
CF2040 RFiLC0121GEZZ J Ceramic Filter AD
SF201 RFiLC0441CEZZ J SAW Filter AH
COILS
L201 VP-XF1R2K0000 J Peaking 1.2µH AB
L202 VP-XF1R2K0000 J Peaking 1.2µH AB
L203 VP-XF220K0000 J Peaking 22µH AB
L204 RCiLi0632CEZZ J VCO Coil AE
L301 VP-XF150K0000 J Peaking 15µH AB
å L701 RCiLF0069PEZZ R Coil (13N-M100/150) AG
or
RCiLF0037PEZZ
or
RCiLF0078PEZZ
or
RCiLF0029PEZZ
or
RCiLF0090CEZZ
å L701 RCiLF0090CEZZ R Coil (CN13M10) AL
L2040 RCiLB0131CEZZ J Oscillation Coil AE
L2201 VP-XFR82K0000 J Peaking 0.82µH AB
TRANSFORMERS
å T601 RTRNZ0168CEZZ J Transformer AH
çå T602 RTRNF0156PEZZ R H-Out Transformer AY
or
RTRNF0151PEZZ
or
RTRNF0148PEZZ
å T701 RTRNP0527CEZZ J Power Transformer AM
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
C51 VCEA0A1CW108M J 1000 16V EL. AD
C53 VCEA0A1HW105M J 1.0 50V EL. AB
C54 VCEA0A1HW475M J 4.7 50V EL. AB
C201 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C202 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C203 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C204 VCQYTA1HM223K J 0.022 50V Mylar AB
C205 VCKYPA1HB103K J 0.01 50V Ceramic AA
C206 VCKYCY1HB102K J 1000p 50V Ceramic AA
C207 VCEA0A1CW476M J 47 16V EL. AB
C208 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C209 VCEA0A1HW105M J 1.0 50V EL. AB
C210 VCEA0A1HW474M J 0.47 50V EL. AB
C211 VCKYCY1HB102K J 1000p 50V Ceramic AA
C212 VCEA0A1HW474M J 0.47 50V EL. AB
C220 VCKYCY1CB104K J 0.1 16V Ceramic AB
C301 VCCCCY1HH470J J 47p 50V Ceramic AA
C302 VCKYCY1HB102K J 1000p 50V Ceramic AA
C303 VCKYPA1HB103K J 0.01 50V Ceramic AA
C304 VCCCCY1HH470J J 47p 50V Ceramic AA
C305 VCKYCY1HB103K J 0.01 50V Ceramic AA
C354 VCEA0A1HW225M J 2.2 50V EL. AB
C356 VCKYCY1HB332K J 3300p 50V Ceramic AA
C357 VCEA0A1HW106M J 10 50V EL. AB
C358 VCEA0A1HW106M J 10 50V EL. AB
C361 VCEA0A1CW108M J 1000 16V EL. AD
C411 VCEA0A1AW108M J 1000 10V EL. AC
C412 VCKYCY1HB103K J 0.01 50V Ceramic AA
C414 VCEA0A1HW225M J 2.2 50V EL. AB
C416 VCEA0A1HW105M J 1.0 50V EL. AB
C418 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C421 VCEA0A1HW106M J 10 50V EL. AB
C451 VCQYTA1HM563K J 0.056 50V Mylar AB
C454 VCEA0A1HW475M J 4.7 50V EL. AB
C455 VCEA0A1CW226M J 22 16V EL. AB
C456 VCEA0A1HW475M J 4.7 50V EL. AB
C509 VCKYPA2HB102K J 1000p 500V Ceramic AA
C510 VCEA0A1VW477M J 470 35V EL. AB
C512 VCFYSA1JA224J J 0.22 63V Mylar AD
C513 VCFYSA1JA473J J 0.047 63V Mylar AC
C514 VCEA0A1EW108M J 1000 25V EL. AD
C515 VCEA0A1HW475M J 4.7 50V EL. AB
C516 VCKYPA1HB222K J 2200p 50V Ceramic AA
C517 VCEA0A1CW226M J 22 16V EL. AB
C520 VCEA0A1HW107M J 100 50V EL. AB
