42
13VT-L200
Note:
1The data of this adjustment is memorized in the E
2
P-
ROM IC.
2Pressing both the CH " (TR —) button and the "0"
button at the same time transmits the test code. When
the unit receives this test code in the slow mode, the
unit is turned into the adjustment mode for the SP or
EP slow tracking preset and "T" is displayed at the
position of CH number on the screen. This function is
available to the remote control : RRMCG1331PESA.
ADJUSTMENT OF STILL PICTURE
VERTICAL SYNC
Measuring Monitor screen
instrument
Mode EP still picture playback
Input signal Self-recording tape
Test point Monitor screen
Control CH '/" (TR ±/ —) buttons
Specification No Vertical jitter
1. Play back the EP Self-recorded tape in the still mode.
2. Using the CH '/" (TR ±/ —) buttons on the remote
control or on the front pannel, make adjustment so that
the vertical jitter becomes minimum.
3. Then press the STOP button to stop the tape.
Note:
The data of this adjustment is memorized to the E
2
P-ROM
IC.
