Sharp 13VT-L200 - Page 96

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
96
13VT-L200
PWB-A: DUNTK9489WEW7
MAIN Unit (Continued)
R7806 VRD-RA2BE103J J 10k 1/8W Carbon AA
å R7807 VRG-SC2EB1R8J J 1.8 1/4W Fuse Res. AE
R7808 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R7809 VRD-RA2BE822J J 8.2k 1/8W Carbon AA
R7810 VRD-RA2BE822J J 8.2k 1/8W Carbon AA
R7811 VRD-RA2BE822J J 8.2k 1/8W Carbon AA
R7812 VRN-MD2AL822J J 8.2k 0.1W Metal Film AA
å R7813 VRG-SC2EB1R2J J 1.2 1/4W Fuse Res. AB
R7818 VRN-MD2AL103J J 10k 0.1W Metal Film AA
R7820 VRN-MD2AL102J J 1.0k 0.1W Metal Film AA
R7821 VRN-MD2AL102J J 1.0k 0.1W Metal Film AA
R7822 VRN-MD2AL104J J 100k 0.1W Metal Film AA
R7823 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R7824 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R7826 VRN-MD2AL103J J 10k 0.1W Metal Film AA
R7827 VRN-MD2AL103J J 10k 0.1W Metal Film AA
R7828 VRN-MD2AL684J J 680k 0.1W Metal Film AA
R7830 VRD-RM2HD561J J 560 1/2W Carbon AA
R7831 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R7832 VRD-RA2BE223J J 22k 1/8W Carbon AA
R7860 VRN-MD2AL103J J 10k 0.1W Metal Film AA
R7863 VRD-RA2BE332J J 3.3k 1/8W Carbon AA
R8301 VRD-RA2BE271J J 270 1/8W Carbon AA
R8303 VRD-RA2BE331J J 330 1/8W Carbon AA
R8304 VRD-RA2BE331J J 330 1/8W Carbon AA
R8305 VRD-RA2BE331J J 330 1/8W Carbon AA
SWITCHES
S2501 QSW-K0079GEZZ J Switch, Eject/Stop AB
S2502 QSW-K0079GEZZ J Switch, Play AB
S2503 QSW-K0079GEZZ J Switch, FF AB
S2504 QSW-K0079GEZZ J Switch, Rew AB
S2506 QSW-K0079GEZZ J Switch, Input AB
S2507 QSW-K0079GEZZ J Switch, CH-Up AB
S2508 QSW-K0079GEZZ J Switch, CH-Down AB
S2509 QSW-K0079GEZZ J Switch, Vol-Up AB
S2510 QSW-K0079GEZZ J Switch, Vol-Down AB
S2512 QSW-K0079GEZZ J Switch, Rec AB
S3101 QSW-P0593CEZZ J Switch, Power AE
S7701 QSW-F0042AJZZ J Switch, Rec Tip AG
MISCELANEOUS PARTS
å F701 QFS-B4023CEZZ J Fuse 4A AC
FB2001 RBLN-0037CEZZ J Ferrite Bead AB
FB7701 RBLN-0036CEZZ J Ferrite Bead AB
FB7702 RBLN-0036CEZZ J Ferrite Bead AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
P350 QPLGN0361CEZZ J Plug 3-pin (O) AB
P401 QPLGZ0840CEZZ J Plug 8-pin (M) AF
P402 QPLGZ1040CEZZ J Plug 10-pin (MB) AE
P404 QPLGN0561CEZZ J Plug 5-pin (GC) AB
P602 QPLGN0603CEZZ J Plug 6-pin (K) AB
P651 QPLGN0361CEZZ J Plug Test Point AB
P703 QPLGN0461CEZZ J Plug 4-pin (YC) AB
P2201 QPLGN0361CEZZ J Plug, Test Point AB
P2401 QPLGN0561CEZZ J Plug, Test Point AB
P3301 QPLGN0352GEZZ J Plug, Test Point AA
P7702 QPLGN0252GEZZ J Plug, Test Point AA
P7706 QPLGZ0883GEZZ J Plug 8-pin (AC) AD
SC3301 QSOCN0611REN1 J Socket 6-pin (AH) AC
SC6601 QSOCN0695REZZ J Socket 6-pin (AA) AB
SC6602 QSOCZ0293GEZZ J Socket 2-pin (AE) AC
SC7701 QSOCN0795REZZ J Socket 7-pin (AD) AC
SC7702 QSOCZ0292GEZZ J Socket 2-pin (AL) AC
RMC3101 RRMCU0222CEZZ J R/C Receiver AL
HM601 LX-GZ3001PEZZ R Screw AB
HM602 LX-GZ3001PEZZ R Screw AB
HM603 LX-GZ3001PEZZ R Screw AB
HM604 LX-GZ3001PEZZ R Screw AB
HM605 LX-GZ3001PEZZ R Screw AB
HM606 LX-GZ3001PEZZ R Screw AB
HM607 LX-GZ3001PEZZ R Screw AB
HM608 LX-GZ3002PEZZ R Screw AB
HM609 LX-GZ3002PEZZ R Screw AB
HM611 LX-GZ3002PEZZ R Screw AB
HM612 LX-GZ3002PEZZ R Screw AB
RDA603 PRDAR0219PEFW R Heat Sink, Q603 AE
RDA501 PRDAR0242PEFW R Heat Sink, IC501 AE
PSLDM0251PEFW R Shield AD
PSLDM0252PEFW R Shield AD
QCNW-2205PEZZ R Connecting Cord AE
QCNW-5508PEN3 R Connecting Cord (OC) AD
LHLDP1057PEZZ R Holder AD
LHLDZ1893AJ00 J Holder AB
LX-BZ3100CEFD J Screw AA
LX-BZ3100CEFD J Screw AA
LX-TZ3004CEFD J Screw AA
PWB-D: DUNTK9518WEV2
FRONT AV Unit
RESISTOR
R431 VRD-RA2BE750J J 75 1/8W Carbon AA
MISCELLANEOUS PARTS
J401 QJAKF0040CEZZ J Jack, AV in AF
