Sharp 13VT-L200 - Page 97

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
97
13VT-L200
PWB-C: DUNTK9490WEW4
POWER Unit
INTEGRATED CIRCUITS
å IC701 VHiSTRF6624-1 J STR-F6624 AW
å IC702 RH-FX0034CEZZ J PC817 AE
å IC703 RH-FX0034CEZZ J PC817 AE
IC756 VHiBA005T//-1 J BA05T AF
IC765 VHiPQ09RD11-1 J PQ09RD11 AG
å IC775 RH-FX0034CEZZ J PC817 AE
TRANSISTORS
Q735 VS2SC3198-Y-1 J 2SC3198 AA
Q750 VSKTA1024-Y-1 J KTA1024 AD
Q751 VS2SC2229O/1E J 2SC2229 AD
Q752 VS2SC2229O/1E J 2SC2229 AD
Q756 VS2SD471-KL1E J 2SD471 AC
DIODES
å D701 RH-DX0154CEZZ J Diode AC
å D702 RH-DX0154CEZZ J Diode AC
å D703 RH-DX0154CEZZ J Diode AC
å D704 RH-DX0154CEZZ J Diode AC
D705 VHD1SS82///1A J Diode AC
D706 VHD10ELS2//-1 J Diode AC
D707 VHD1SS82///1A J Diode AC
D708 VHSSFOR5D43-1 J Si. Control Rectifier AC
D709 RH-EX0610GEZZ J Zener Diode AA
D711 RH-EX0207CEZZ J Zener Diode AA
D722 VHD1SS82///1A J Diode AC
D725 RH-DX0469CEZZ J Diode AF
D726 RH-DX0469CEZZ J Diode AF
D727 RH-DX0461CEZZ J Diode AG
D735 RH-EX0617GEZZ J Zener Diode AA
D739 RH-EX0602GEZZ J Zener Diode AA
D740 VHD1SS82///1A J Diode AC
D743 VHD1SS119//-1 J Diode AB
D744 VHD1SS119//-1 J Diode AB
D751 RH-EX0617GEZZ J Zener Diode AA
å D775 RH-DX0441CEZZ J Diode AC
å D776 RH-DX0279CEZZ J Diode AB
PR702 RMPTP0026CEZZ J Packaged Circuit AF
COILS
L725 RCiLP0195CEZZ J Coil AD
L726 RCiLP0179CEZZ J Coil AD
L727 RCiLP0179CEZZ J Coil AD
TRANSFORMER
å T701 RTRNZ0114PEZZ R Transformer AR
CONTROL
R738 RVR-M4333CEZZ J 6.8k (B) 115V Adj. AC
CAPACITORS
(EL. : Electrolytic)
å C702 VCKYPB2HE103P J 0.01 500V Ceramic AB
å C703 VCKYPB2HE103P J 0.01 500V Ceramic AB
C705 RC-EZ0613CEZZ J 470 200V EL. AL
C706 RC-KZ0404CEZZ J 0.0033 2kV Ceramic AE
C708 VCCSPA1HL471J J 470p 50V Ceramic AA
C709 VCEA0A1HW107M J 100 50V EL. AB
C710 VCQYTA1HM222J J 2200p 50V Mylar AA
C711 VCFYFA1HA224J J 0.22 50V Mylar AB
å C712 RC-KZ0312CEZZ J 0.0047 Ceramic AD
C722 VCKYPA1HB102K J 1000p 50V Ceramic AA
C723 VCKYPA1HB102K J 1000p 50V Ceramic AA
C724 VCKYPA1HB102K J 1000p 50V Ceramic AA
C725 VCKYPA1HB102K J 1000p 50V Ceramic AA
C726 VCEAGH1EW228M J 2200 25V EL. AE
C727 VCEAHV1CN108M J 1000 16V EL. AE
C728 RC-KZ0365CEZZ J 0.001 2kV Ceramic AD
C729 RC-KZ0365CEZZ J 0.001 2kV Ceramic AD
C730 RC-EZ0724CEZZ J 100 160V EL. AG
C735 VCCCPA1HH680J J 68p 50V Ceramic AA
C739 VCEA0A1HW104M J 0.1 50V EL. AB
C748 VCEA0A1HW107M J 100 50V EL. AB
C756 VCEA0A1CW476M J 47 16V EL. AB
C757 VCEA0A0JW107M J 100 6.3V EL. AB
C758 VCEA0A1CW226M J 22 16V EL. AB
C759 VCEA0A1AW476M J 47 10V EL. AB
C768 VCEA0A1CW476M J 47 16V EL. AB
C769 VCEA0A1CW476M J 47 16V EL. AB
C775 VCKYPA1HB103K J 0.01 50V Ceramic AA
RESISTORS
(M-Ox. : Metal Oxide)
å R701 VRW-KP3HC1R8K J 1.8 5W Cement AC
å R703 VRC-UB2HG275K J 2.7M 1/2W Solid AF
R704 VRD-RM2HD154J J 150k 1/2W Carbon AA
R706 RR-NZ0048CEZZ J 0.15 2W AD
R707 VRS-SV2HC471J J 470 1/2W M-Ox. AA
R709 VRN-GA2EB1R0J J 1.0 1/4W Metal Film AA
R710 VRD-RM2HD180J J 18 1/2W Carbon AA
R711 VRD-RA2EE122J J 1.2k 1/4W Carbon AA
R713 VRS-SV2HC272J J 2.7k 1/2W M-Ox. AA
R714 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R715 VRD-RA2BE153J J 15k 1/8W Carbon AA
R716 VRD-RA2EE152J J 1.5k 1/4W Carbon AA
R717 VRD-RM2HD104J J 100k 1/2W Carbon AA
R719 VRW-KQ3HC4R7K J 4.7 5W Cement AE
R727 VRS-VV3DB223J J 22k 2W M-Ox. AA
R733 VRD-RA2EE152J J 1.5k 1/4W Carbon AA
R735 VRD-RA2EE681J J 680 1/4W Carbon AA
R736 VRD-RM2HD563J J 56k 1/2W Carbon AA
R737 VRD-RA2EE824J J 820k 1/4W Carbon AA
R739 VRD-RA2EE681J J 680 1/4W Carbon AA
R740 VRD-RM2HD470J J 47 1/2W Carbon AA
R741 VRN-RA2BK332F J 3.3k 1/8W Metal Film AA
R743 VRD-RM2HD823J J 82k 1/2W Carbon AA
