Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
44
14U10/15
14U20/25
C314 VCEA0A1EW477M R 470 25V Electrolytic AD
C315 VCKYPA1HF103Z R 0.01 50V Ceramic AA
C317 VCEA0A1CW106M R 10 16V Electrolytic AB
C318 VCKYCY1HB102K R 1000p 50V Ceramic AA
C319 VCE9GA1EW476M R 47 25V Electrolytic AC
C331 VCEA0A1HW105M R 1 50V Electrolytic AB
C332 VCEA0A1EW477M R 470 25V Electrolytic AD
C333 VCKYPA2HB102K R 1000p 500V Ceramic AA
C356 VCKYCY1HB682K R 6800p 50V Ceramic AA
C359 VCEA9M1CW106M R 10 16V Electrolytic AB
C360 VCEA9M1HW225M R 2.2 50V Electrolytic AB
(14U20/25)
C364 VCEA0A1CW106M R 10 16V Electrolytic AB
C371 VCEA0A1CW476M R 47 16V Electrolytic AB
C373 VCEA0A1CW107M R 100 16V Electrolytic AC
(14U20/25)
C374 VCEA0A1HW225M R 2.2 50V Electrolytic AB
(14U20/25)
C375 VCEAEA1HW225M R 2.2 50V Electrolytic AB
(14U20/25)
C379 VCEA0A1HW335M R 3.3 50V Electrolytic AB
(14U20/25)
C390 VCEA0A1HW105M R 1 50V Electrolytic AB
C405 VCEA0A1CW107M R 100 16V Electrolytic AC
(14U20/25)
C406 VCEA0A1CW477M R 470 16V Electrolytic AC
C407 VCEA0A1CW106M R 10 16V Electrolytic AB
(14U20/25)
C408 VCEA0A1CW106M R 10 16V Electrolytic AB
C409 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C410 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C411 VCKYCY1HB102K R 1000p 50V Ceramic AA
C412 VCKYCY1HB472K R 4700p 50V Ceramic AA
(14U20/25)
C415 VCKYCY1HB102K R 1000p 50V Ceramic AA
(14U20/25)
C469 VCEA0A1HW105M R 1 50V Electrolytic AB
C501 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C502 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C503 VCEA0A1EW108M R 1000 25V Electrolytic AD
C504 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C506 VCQYTA1HM104J R 0.1 50V Mylar AA
C507 VCEA0A1JW107M R 100 63V Electrolytic AC
C508 VCQYTA1HM103J R 0.01 50V Mylar AA
C512 VCKYCY1HB102K R 1000p 50V Ceramic AA
C513 VCKYCY1HB102K R 1000p 50V Ceramic AA
C514 VCKYPA1HF103Z R 0.01 50V Ceramic AA
C515 VCKYPA2HB102K R 1000p 500V Ceramic AA
C516 VCEA0A1JW477M R 470 63V Electrolytic AE
C517 VCFYFA1HA104J R 0.1 50V AA
MetalIzed Polypro Film
C601 VCEAGA2EW106M R 10 250V Electrolytic AC
C602 VCQYTA1HM104J R 0.1 50V Mylar AA
C603 VCEA0A1HW105M R 1 50V Electrolytic AB
C604 VCEA0A1HW105M R 1 50V Electrolytic AB
C605 VCKYPA1HF103Z R 0.01 50V Ceramic AA
C606 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C607 VCEA0A1CW477M R 470 16V Electrolytic AC
C608 VCEA0A1EW476M R 47 25V Electrolytic AB
C609 VCEA0A1EW108M R 1000 25V Electrolytic AD
C610 VCFYSB2EB823J R 0.082 250V AD
MetalIzed Polypro Film
C611 VCKYPA2HB102K R 1000p 500V Ceramic AA
C612 RC-EZ0724CEZZ R 100 160V Electrolytic AG
C613 VCFPVC2DB105J R 1 200V
MetalIzed Polypro Film
C615 VCFPVC2DB224J R 0.22 200V AE
MetalIzed Polypro Film
C616 VCFPPD3CA682H R 6800p 1600V AE
MetalIzed Polypro Film
C617 VCKYPA2HB102K R 1000p 500V Ceramic AA
C620 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C623 VCQYTA1HM222J R 2200p 50V Mylar AA
C624 VCQYTA1HM472J R 4700p 50V Mylar AB
C625 VCEA0A1HW105M R 1 50V Electrolytic AB
C626 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C627 VCEA0A1HW106M R 10 50V Electrolytic AB
C628 VCEA0A1HW474M R 0.47 50V Electrolytic AB
D756 RH-DX0471CEZZ R DX0471CE AE
D757 RH-DX0471CEZZ R DX0471CE AE
D758 RH-DX0461CEZZ R DX0471CE AG
D759 RH-EX0716GEZZ R Zener Diode AB
D760 VHD1SS119//-1 R 1SS119 AB
D761 VHD1SS119//-1 R 1SS119 AB
D762 VHDTF321S//-1 R TF321S AH
D801 VHD1SS119//-1 R 1SS119 AB
D802 VHD1SS119//-1 R 1SS119 AB
D803 VHD1SS119//-1 R 1SS119 AB
D804 VHD1SS119//-1 R 1SS119 AB
D805 VHD1SS119//-1 R 1SS119 AB
D806 VHD1SS119//-1 R 1SS119 AB
D1001 RH-PX0423CEZZ R LED AD
D1004 VHD1SS119//-1 R 1SS119 AB
D1007 RH-EX0867CEZZ R Zener Diode AC
D1008 RH-EX0867CEZZ R Zener Diode AC
D1009 RH-EX0867CEZZ R Zener Diode AC
D1010 RH-EX0867CEZZ R Zener Diode AC
å IC702 RH-FX0008GEZZ R PC123FY8 AE
å VA700 RH-VX0047CEZZ R Varistor AF
PACKAGED CIRCUITS
PR702 RMPTP0028CEZZ R Packaged Circuit AG
TH701 VHHNTH13D//-1 R Thermistor AF
X1001 RCRSB0281CEZZ R Crystal, CRSB0281CE AG
COILS
L202 VP-DF270K0000 R Peaking, 27µHAB
L203 VP-DF270K0000 R Peaking, 27µHAB
L204 VP-XF1R2K0000 R Peaking, 1.2µHAB
L205 VP-DF1R0K0000 R Peaking, 1µHAB
L207 VP-DF1R0K0000 R Peaking, 1µHAB
L209 VP-XF6R8K0000 R Peaking, 6.8µHAB
L301 VP-DF1R0K0000 R Peaking, 1µH(14U20/25) AB
L401 VP-DF1R0K0000 R Peaking, 1µH(14U20/25) AB
L601 VP-CF1R0M0000 R Peaking, 1µHAB
L603 RCiLP0225CEZZ R Coil, CiLP0225CE AF
å L702 RCiLF0019PEZZ R Coil, CiLF0019PE AN
L802 VP-DF100K0000 R Peaking, 10µHAB
L803 VP-DF100K0000 R Peaking, 10µHAB
L1030 VP-DF100K0000 R Peaking, 10µHAB
L1050 VP-DF100K0000 R Peaking, 10µHAB
L1051 VP-DF100K0000 R Peaking, 10µHAB
FILTERS
CF202 RFiLC0020CEZZ R Filter, FiLC0020CE AE
SF201 RFiLC0442CEZZ R Filter, FiLC0442CE AL
TRANSFORMERS
å T602 RTRNF0193PEN1 R H-Volt Transformer AZ
å T603 RTRNZ0179CEZZ R Transformer AE
å T701 RTRNZ0180PEZZ R Transformer AN
CAPACITORS
C200 VCEA0A1CW476M R 47 16V Electrolytic AB
C203 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C204 VCEA0A1CW107M R 100 16V Electrolytic AC
C205 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C206 VCEA0A1HW106M R 10 50V Electrolytic AB
C207 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C208 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C209 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C210 VCKYCY1HF103Z R 0.01 50V Ceramic AA
C211 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C212 VCEA0A1CW106M R 10 16V Electrolytic AB
C213 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C215 VCEA0A1CW476M R 47 16V Electrolytic AB
C216 VCKYCY1HB821K R 820p 50V Ceramic AA
C217 VCKYCY1HB472K R 4700p 50V Ceramic AA
C301 VCEA0A1CW107M R 100 16V Electrolytic AC
(14U20/25)
C302 VCEA0A1HW225M R 2.2 50V Electrolytic AB
C303 VCEA0A1CW106M R 10 16V Electrolytic AB
C304 VCQYTA1HM473J R 0.047 50V Mylar AA
C305 VCQYTA1HM473J R 0.047 50V Mylar AA
C312 VCQYTA1HM123J R 0.012 50V Mylar AA
