Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
45
14U10/15
14U20/25
RJ16 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ21 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ25 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ26 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ27 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ29 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ30 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ31 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ32 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ33 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ34 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ41 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ43 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ50 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14U10/15)
RJ51 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ53 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ61 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ62 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ64 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ66 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ67 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14U10/15)
RJ68 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ69 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ71 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ74 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ75 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ76 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ78 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ79 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ80 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ84 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ85 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ87 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ88 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ89 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ94 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ96 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ97 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14U20/25)
RJ100 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14U20/25)
RJ103 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ105 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14U20/25)
RJ201 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ202 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ204 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14U20/25)
RJ205 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ206 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ207 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14U10/15)
RJ209 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14U20/25)
RJ210 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14U20/25)
R201 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R202 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R203 VRD-RM2HD102J R 1k 1/2W Carbon AA
R204 VRD-RM2HD102J R 1k 1/2W Carbon AA
R205 VRD-RA2BE680J R 68 1/8W Carbon AA
R206 VRS-CY1JF122J R 1.2k 1/16W Metal Oxide AA
R207 VRS-CY1JF221J R 220 1/16W Metal Oxide AA
R208 VRS-CY1JF122J R 1.2k 1/16W Metal Oxide AA
R209 VRS-CY1JF392J R 3.9k 1/16W Metal Oxide AA
R217 VRD-RA2BE392J R 3.9k 1/8W Carbon AA
R218 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R219 VRS-CY1JF391J R 390 1/16W Metal Oxide AA
R220 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R221 VRS-CY1JF102J R 1k 1/16W Metal Oxide AA
R222 VRS-CY1JF681J R 680 1/16W Metal Oxide AA
R226 VRS-CY1JF750J R 75 1/16W Metal Oxide AA
R227 VRD-RM2HD330J R 33 1/2W Carbon AA
R228 VRD-RM2HD330J R 33 1/2W Carbon AA
R230 VRS-CY1JF101J R 100 1/16W Metal Oxide AA
R231 VRS-CY1JF182J R 1.8k 1/16W Metal Oxide AA
C650 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C654 VCEA0A1CW476M R 47 16V Electrolytic AB
C700 VCQYTA2AA103K R 0.01 100V Mylar AC
å C701 RC-FZ031SCEZZ R 0.1 250V AD
MetalIzed Polypro Film
C702 RC-KZ0160GEZZ R 0.01 250V Ceramic AC
C703 RC-KZ0160GEZZ R 0.01 250V Ceramic AC
C704 VCKYPA2HB102K R 1000p 500V Ceramic AA
C705 VCKYPA2HB102K R 1000p 500V Ceramic AA
C707 RC-EZ1044CEZZ R 150 400V Electrolytic AM
C708 RC-KZ0160GEZZ R 0.01 250V Ceramic AC
C709 VCQYTA1HM471J R 470p 50V Mylar AB
C711 RC-KZ0039CEZZ R 680p 2kV Ceramic AB
C712 VCQYTA1HM102J R 1000p 50V Mylar AA
C713 RC-KZ007JCEZZ R 0.01 250V Ceramic AC
C714 VCKYPH3DB561K R 560p 2000V Ceramic AC
C715 VCKYPA2HB102K R 1000p 500V Ceramic AA
C717 VCQYTA1HM182J R 1800p 50V Mylar AA
C718 VCEAGA2AW475M R 4.7 100V Electrolytic AB
C719 VCEA9M1HW226M R 22 50V Electrolytic AB
å C721 RC-KZ0102GEZZ R 680p 4kV Ceramic AE
C751 VCEA0A1CW476M R 47 16V Electrolytic AB
C752 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C753 VCKYPA2HB102K R 1000p 500V Ceramic AA
C755 VCEA0A1CW108M R 1000 16V Electrolytic AD
C756 VCEA0A1CW338M R 3300 16V Electrolytic AE
C758 VCKYPA1HB221K R 220p 50V Ceramic AA
å C759 VCKYPA1HB102K R 1000p 50V Ceramic AA
C760 RC-KZ0039CEZZ R 680p 2kV Ceramic AB
C761 RC-EZ0724CEZZ R 100 160V Electrolytic AG
C762 VCQYTA1HM473J R 0.047 50V Mylar AA
C801 VCEA0A1HW105M R 1 50V Electrolytic AB
C802 VCEA0A1CW108M R 1000 16V Electrolytic AD
C803 VCEA9M1CW107M R 100 16V Electrolytic AB
C804 VCKYCY1HB222K R 2200p 50V Ceramic AA
C805 VCKYCY1HB102K R 1000p 50V Ceramic AA
C806 VCKYCY1HB102K R 1000p 50V Ceramic AA
C807 VCKYCY1HB102K R 1000p 50V Ceramic AA
C808 VCEA0A1CW107M R 100 16V Electrolytic AC
C809 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C810 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C811 VCEA0A1CW107M R 100 16V Electrolytic AC
C812 VCFYFA1HA224J R 0.22 50V AB
MetalIzed Polypro Film
C813 VCFYFA1HA224J R 0.22 50V AB
MetalIzed Polypro Film
C814 VCKYCY1HB471K R 470p 50V Ceramic AA
C1001 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1003 VCEA0A1CW106M R 10 16V Electrolytic AB
C1004 VCKYCY1EF104Z R 0.1 25V Ceramic AA
C1005 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C1006 VCEA0A1CW106M R 10 16V Electrolytic AB
C1007 VCEA0A1CW106M R 10 16V Electrolytic AB
C1008 VCCCCY1HH330J R 33p 50V Ceramic AA
C1009 VCCCCY1HH330J R 33p 50V Ceramic AA
C1010 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1011 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C1012 VCKYCY1HF223Z R 0.022 50V Ceramic AB
C1013 VCEA0A0JW107M R 100 6.3V Electrolytic AB
C1014 VCEA0A1CW106M R 10 16V Electrolytic AB
C1015 VCFYFA1HA474J R 0.47 50V AC
MetalIzed Polypro Film
C1016 VCQYTA1HM104J R 0.1 50V Mylar AA
C1018 VCKYCY1HB221K R 220p 50V Ceramic AA
C1019 VCEA9M1HW225M R 2.2 50V Electrolytic AB
C1023 VCEA0A1CW107M R 100 16V Electrolytic AC
RESISTORS
RJ2 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ9 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14U20/25)
RJ10 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
(14U20/25)
RJ11 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ12 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ13 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
RJ15 VRS-CY1JF000J R 0 1/16W Metal Oxide AA
