19J-M100/100S/150/20J-M100
CJ19M10/CJ20M10/ 20MJ10
S01 PICTURE 55 00-7F
S02 TINT 46 00-7F
S03 COLOR 32 00-7F
S04 BRIGHTNESS 40 00-7F
S05 SHARPNESS 28 00-3F Must be set to “24”
S06 VERTICAL PHASE 00 00-07 Must be set to “00”~"03"
S07 HORIZONTAL PHASE 12 00-1F
S08 RF-AGC 2A 00-3F
S09 VERTICAL AMP 20 00-3F
S10 VCO 2C 00-7F
S11 R CUT-OFF 00 00-FF
S12 G CUT -OFF 00 00-FF
S13 B CUT-OFF 00 00-FF
S14 G GAIN 7F 00-FF
S15 B GAIN 7F 00-FF
S16 TRAP(3.58MHz) 00 00 or 01 Must be set to “00”
S17 BALANCE 20 00-3F Must be set to “20”
S18 C.C.POSITION 18 00-7F
S19 Y-MUTE 00 00,01,03 00=NORMAL, 01=no”Y, 03=NO VERTICAL”
SERVICE
NUMBER
DATA
ADJUSTMENT CONTENTS
ADJUSTMENT ITEM
RANGE
Holding down both the CH UP/DOWN keys on the TV set at service mode for more then 2 seconds will automatically
write the above initial values into IC2101.
NECESSARY
UNNECESSARY
ADJUSTMENT
NOTES
PART REPLACED
IC2001
IC201
IC2101
CRT
The adjustment is needed to compensate for
characteristics of parts including IC201.
Data is stored in IC2101.
Adjust items related to picture tube only.
Holding down both the CH UP/DOWN keys on the TV set
at service mode for more than 2 seconds will automatically
write the above initial values into IC2101.
INITIAL VALUE
X
X
X
X
Table - A
Table - B
To Next Page
