Sharp 19J-M100

32
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
19J-M100/100S/150/CJ19M10
20J-M100/CJ20M10/20MJ10
DUNTK9273WEV0/V2/V4/V5
DUNTK9316WEV0/V2 MAIN UNIT
TRANSISTORS
Q852 VS2SC2229O/1E J 2SC2229(O) AD
Q854 VS2SC2229O/1E J 2SC2229(O) AD
Q856 VS2SC2229O/1E J 2SC2229(O) AD
Q881 VS2SA1266-Y-1 J 2SA1266(Y) AA
DIODES
D881 VHD1SS119//-1 J Diode AB
D882 VHD1SS119//-1 J Diode AB
D885 VHD1SS119//-1 J Diode AB
COILS
L851 VP-DF151K0000 J 150µH AB
R859 VRN-MD2AL470J J 47 0.1W Metal.Film AA
R859 VRN-MD2AL470J J 47 0.1W Metal.Film AA
CAPACITORS
C851 VCCCCY1HH271J J 270p 50V Ceramic AA
C852 VCCCCY1HH271J J 270p 50V Ceramic AA
C853 VCCCCY1HH271J J 270p 50V Ceramic AA
C854 RC-KZ0016CEZZ J 0.1 1.4kV Ceramic AC
C858 VCKYCY1HB102K J 1000p 50V Ceramic AA
C881 VCEA0A1CW106M J 10 16V EL. AB
C883 VCEA0A1CW336M J 33 16V EL. AB
RESISTORS
R851 VRN-MD2AL470J J 47 0.1W Metal.Film AA
R852 VRD-RA2BE271J J 270 1/8W Carbon AA
R853 VRN-MD2AL121J J 120 0.1W Metal.Film AA
å R857 VRS-VV3AB123J J 12k 1W Metal.OxideAA
R858 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R859 VRN-MD2AL470J J 47 0.1W Metal.Film AA
R859 VRD-RA2BE470J J 47 1/8W Metal.Film AA
(19J-M100S/20MJ10)
R860 VRD-RA2BE271J J 270 1/8W Carbon AA
R860 VRD-MD2AL221J J 220 0.1W Carbon AA
(19J-M100S/20MJ10)
R861 VRN-MD2AL121J J 120 0.1W Metal.Film AA
å R865 VRS-VV3AB123J J 12k 1W Metal.Oxide AA
R866 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R867 VRD-RA2BE470J J 47 1/8W Carbon AA
R867 VRD-MD2AL470J J 47 0.1W Carbon AA
(19J-M100S/20MJ10)
R868 VRN-MD2AL271J J 270 0.1W Metal.Film AA
R868 VRD-RA2BE221J J 220 1/8W Metal.Film AA
(19J-M100S/20MJ10)
R869 VRN-MD2AL121J J 120 0.1W Metal.Film AA
å R873 VRS-VV3AB123J J 12k 1W Metal.Oxide AA
R874 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R881 VRN-MD2AL561J J 560 0.1W Metal.Film AA
R882 VRN-MD2AL391J J 390 0.1W Metal.Film AA
R883 VRD-RA2BE561J J 560 1/8W Carbon AA
R884 VRN-MD2AL152J J 1.5k 0.1W Metal.Film AA
R886 VRN-MD2AL431J J 430 0.1W Metal.Film AA
DUNTK9274WEV0/V2
DUNTK9317WEV0 CRT UNIT
R2049 VRN-MD2AL333J J 33k 0.1W Metal.Film AA
R2054 VRN-MD2AL103J J 10k 0.1W Metal.Film AA
R2055 VRN-MD2AL103J J 10k 0.1W Metal.Film AA
R2060 VRN-MD2AL221J J 220 0.1W Metal.Film AA
R2061 VRN-MD2AL562J J 5.6k 0.1W Metal.Film AA
R2062 VRN-MD2AL183J J 18k 0.1W Metal.Film AA
R2063 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R2064 VRD-RA2BE332J J 3.3k 1/8W Carbon AA
R2066 VRN-MD2AL103J J 10k 0.1W Metal.Film AA
R2067 VRN-MD2AL103J J 10k 0.1W Metal.Film AA
R2068 VRN-MD2AL103J J 10k 0.1W Metal.Film AA
R2070 VRN-MD2AL103J J 10k 0.1W Metal.Film AA
R2101 VRN-MD2AL101J J 100 0.1W Metal.Film AA
R2102 VRN-MD2AL101J J 100 0.1W Metal.Film AA
R2501 VRN-MD2AL123J J 12k 0.1W Metal.Film AA
R2503 VRN-MD2AL273J J 27k 0.1W Metal.Film AA
R2504 VRN-MD2AL123J J 12k 0.1W Metal.Film AA
R2505 VRN-MD2AL563J J 56k 0.1W Metal.Film AA
R2506 VRD-RA2BE563J J 56k 1/8W Carbon AA
R2507 VRN-MD2AL823J J 82k 0.1W Metal.Film AA
R2508 VRN-MD2AL153J J 15k 0.1W Metal.Film AA
R2509 VRN-MD2AL272J J 2.7k 0.1W Metal.Film AA
R2601 VRD-RA2BE470J J 47 1/8W Carbon AA
MISCELLANEOUS PARTS
S2501 QSW-K0079GEZZ J Switch,Power AB
S2502 QSW-K0079GEZZ J Switch,Vol-down AB
S2503 QSW-K0079GEZZ J Switch,Vol-up AB
S2504 QSW-K0079GEZZ J Switch,Ch-down AB
S2505 QSW-K0079GEZZ J Switch,Ch-up AB
å RY701 RRLYU0036CEZZ J Relay AM
or RRLYU0028CEZZ
å F701 QFS-B4023CEZZ J Fuse AC
or QFS-B4021GEZZ
FB602 RBLN-0037CEZZ J Balun AB
FB603 RBLN-0037CEZZ J Balun AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
J903 QJAKE0159CEZZ J Jack AF
J905 QJAKE0158CEZZ J Jack AF
P302 QPLGN0261CEZZ J Plug AB
P401 QPLGN0561CEZZ J Plug AB
P601 QPLGN0603CEZZ J Plug AB
P651 QPLGN0361CEZZ J Plug AB
P701 QPLGN0207CEZZ J Plug AA
P751 QPLGN0461CEZZ J Plug AB
P2001 QPLGN0561CEZZ J Plug AB
RMC2601 RRMCU0222CEZZ J Remote Receiver AL
or RRMCU0216CEZZ
RDA501PRDAR0218PEFW R Heat Sink AD
RDA602PRDAR0216PEFW R Heat Sink AE
RDA701PRDAR0238PEFW R Heat Sink AN
or PRDAR3189PEFW
TP701 QLUGP0102PEZZ R Lug AA
